Airtac MFJ Adjustable Mini Cylinder MFJ20X125-30
$43.70
Regular price
$51.20
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
MFJ20X125-30
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Complies with JS standards;
2. Features an asymmetric bidirectional sealing structure for piston sealing, offering compact dimensions with integrated oil reservoir functionality;
3. Integrated fixed cushions on both end covers minimize impact during directional changes;
4. Multiple rear cover configurations simplify installation and enhance mounting flexibility;
5. Crimped and wrapped assembly ensures robust connection between stainless steel barrel and end covers;
6. Precision-engineered stainless steel barrel provides exceptional strength and corrosion resistance;
7. MF series achieves shorter overall length than ISO6432 standard cylinders while maintaining identical bore/stroke specifications;
8. Comprehensive range of cylinder variants and mounting accessories available for customized solutions.
Category: Adjustable Cylinders | Brand: AirTAC | Series: MFJ Adjustable cylinders
Installation protocol:
For optimal performance, maintain 0.3-1.0MPa clean air supply with 40μm filtration.
When using adjustable stroke feature, apply thread-locking compound to prevent
accidental nut rotation during vibration. Alignment tolerance: ±0.5mm lateral offset.
2. Features an asymmetric bidirectional sealing structure for piston sealing, offering compact dimensions with integrated oil reservoir functionality;
3. Integrated fixed cushions on both end covers minimize impact during directional changes;
4. Multiple rear cover configurations simplify installation and enhance mounting flexibility;
5. Crimped and wrapped assembly ensures robust connection between stainless steel barrel and end covers;
6. Precision-engineered stainless steel barrel provides exceptional strength and corrosion resistance;
7. MF series achieves shorter overall length than ISO6432 standard cylinders while maintaining identical bore/stroke specifications;
8. Comprehensive range of cylinder variants and mounting accessories available for customized solutions.
Category: Adjustable Cylinders | Brand: AirTAC | Series: MFJ Adjustable cylinders
AirTAC MFJ Adjustable Miniature Cylinder MFJ20X125-30 Specifications
- Model: MFJ20X125-30
- Series: MFJ (Compact Adjustable Stroke)
- Bore size: 20mm
- Stroke: 125mm ±0.5mm (adjustable)
- Mounting type: Basic type with axial mounting holes
- Operation direction: Double-acting
- Cushion type: Rubber buffer + adjustable stroke mechanism
- Port size: M5x0.8 (standard) or NPT1/8 optional
- Operating pressure: 0.05-1.0 MPa
- Temperature range: -20℃ to 80℃
- Cylinder tube material: Anodized aluminum alloy
- Piston rod material: Stainless steel (SUS304)
- Seal material: NBR (Nitrile) with polyurethane wear rings
- Adjustable stroke range: 0-30mm (via external locking nut)
- Weight: 680g ±5% (without accessories)
- Dimensions:
- Extended length: 229mm
- Retracted length: 104mm
- Body width: 34mm
- Mounting hole spacing: 25mm (axial)
- Lubrication: Pre-lubricated (Oil-free operation possible)
- ISO standard: Compliant with ISO 6432 (miniature cylinders)
Ultra-compact pneumatic cylinder featuring a unique stroke adjustment mechanism with ±1.5° angular compensation. The double-layer chromium-plated piston rod and multi-lip seals ensure 5000km+ service life under standard conditions. Includes built-in magnetic sensor slots (M5 mounting) for position feedback integration.
Industrial Applications:
- PCB handling robots - precision component placement
- Pharmaceutical blister packaging machines
- Semiconductor wafer transfer systems
- Automated test equipment (ATE) fixture actuation
- Medical device assembly lines
Installation protocol:
For optimal performance, maintain 0.3-1.0MPa clean air supply with 40μm filtration.
When using adjustable stroke feature, apply thread-locking compound to prevent
accidental nut rotation during vibration. Alignment tolerance: ±0.5mm lateral offset.
Service cycle: Relubricate every 3 million cycles (using ISO VG32 turbine oil).
Replace cushion seals after 10 million cycles in high-speed applications (>500mm/s).
| Property | Property Value |
|---|---|
| sku | MFJ20X125-30 |
| Adjustable Stroke | 30mm |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Stroke | 125mm |
