Airtac MI16-20 Stainless Steel Mini Cylinder MI16X100CA
$26.74
Regular price
$34.24
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
MI16X100CA
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Compliant with ISO 6432 standard (Bore sizes: 8-25mm);
2. Integrated fixed cushion rings on front/rear covers minimize impact during stroke reversal;
3. Multiple rear cover configurations enhance installation flexibility;
4. Crimped roller-clad structure ensures robust connection between stainless steel cylinder barrel and end covers;
5. Full stainless steel construction (piston rod & barrel) provides corrosion resistance for demanding environments;
6. Available in multiple configurations with comprehensive mounting accessories.
Category: Stainless Steel Mini Cylinders | Brand: AirTAC | Series: MI16~20
Installation note:
Lubricate with ISO VG32 turbine oil before initial use. Avoid side load exceeding 1.5N·m.
For vertical mounting, use rod-down orientation to prevent moisture accumulation.
Requires 5μm filtered air with dew point -20℃ below ambient.
2. Integrated fixed cushion rings on front/rear covers minimize impact during stroke reversal;
3. Multiple rear cover configurations enhance installation flexibility;
4. Crimped roller-clad structure ensures robust connection between stainless steel cylinder barrel and end covers;
5. Full stainless steel construction (piston rod & barrel) provides corrosion resistance for demanding environments;
6. Available in multiple configurations with comprehensive mounting accessories.
Category: Stainless Steel Mini Cylinders | Brand: AirTAC | Series: MI16~20
AirTAC MI16X100CA Stainless Steel Mini Cylinder Specifications
- Model: MI16X100CA
- Series: MI16~20 (16mm bore size variant)
- Bore diameter: 16mm
- Stroke: 100mm
- Operating pressure: 0.15–0.8 MPa
- Temperature range: -20℃ to 80℃
- Port size: M5x0.8 (dual ports)
- Mounting type: Standard foot mounting (MF1) with optional front flange
- Cushioning: Adjustable rubber buffer (both ends)
- Material: Stainless steel (SUS304 barrel, CR-SUS piston rod)
- Seal material: NBR/FKM optional (standard NBR)
- Weight: 0.25kg ±5%
- Dimensions: 160mm(L) × 32mm(W) × 32mm(H) (extended length)
- Rod thread: M6x1.0 external thread
- Max theoretical thrust: 31.4N @0.5MPa
- ISO standard: 6432 compliant
Corrosion-resistant mini cylinder optimized for compact automation systems. Features precision-machined SUS304 barrel with chrome-plated stainless steel piston rod for harsh environments. Dual cushion adjustment prevents impact damage during high-speed cycling (≤1.5m/s).
Typical Applications:
- Semiconductor wafer handling robots
- Pharmaceutical liquid dispensing systems
- Food packaging machinery (NSF-compliant with FKM seals)
- Micro-positioning in optical equipment assembly
- Cleanroom automation (ISO Class 5-8 environments)
Installation note:
Lubricate with ISO VG32 turbine oil before initial use. Avoid side load exceeding 1.5N·m.
For vertical mounting, use rod-down orientation to prevent moisture accumulation.
Requires 5μm filtered air with dew point -20℃ below ambient.
| Property | Property Value |
|---|---|
| sku | MI16X100CA |
| Rear Cover Type | Swivel Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Bore Diameter | 16mm |
| Stroke | 100mm |
