Airtac MI16-20 Stainless Steel Mini Cylinder MI16X100R
$26.74
Regular price
$34.24
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
MI16X100R
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Compliant with ISO 6432 standard (Bore sizes: 8-25mm);
2. Integrated fixed cushion rings on front/rear covers minimize impact during stroke reversal;
3. Multiple rear cover configurations enhance installation flexibility;
4. Crimped roller-clad structure ensures robust connection between stainless steel cylinder barrel and end covers;
5. Full stainless steel construction (piston rod & barrel) provides corrosion resistance for demanding environments;
6. Available in multiple configurations with comprehensive mounting accessories.
Category: Stainless Steel Mini Cylinders | Brand: AirTAC | Series: MI16~20
Maintenance Alert:
Apply NSF-H1 grease annually for food-grade applications. Avoid side-load exceeding 2N·m.
Use brass fittings to prevent galvanic corrosion.
2. Integrated fixed cushion rings on front/rear covers minimize impact during stroke reversal;
3. Multiple rear cover configurations enhance installation flexibility;
4. Crimped roller-clad structure ensures robust connection between stainless steel cylinder barrel and end covers;
5. Full stainless steel construction (piston rod & barrel) provides corrosion resistance for demanding environments;
6. Available in multiple configurations with comprehensive mounting accessories.
Category: Stainless Steel Mini Cylinders | Brand: AirTAC | Series: MI16~20
AirTAC MI16X100R Stainless Steel Mini Cylinder Specifications
- Model Series: MI16~20 (MI16X100R specific)
- Bore Size: 16mm (Standard MI series sizing)
- Stroke: 100mm (Customizable from 10-300mm)
- Material: SUS304 Stainless Steel (Body/Rod)
- Operating Pressure: 0.05-0.8 MPa
- Temperature Range: -20℃ to 150℃ (Seal dependent)
- Piston Speed: 50-700mm/s (Optimal at 200mm/s)
- Cushioning: Adjustable rubber bumper (Dual-side)
- Port Size: M5x0.8 (Dual auto-switch grooves optional)
- Rod Thread: M6x1.0 (Internal/External optional)
- Weight: 280g ±5% (Without accessories)
- Dimensions:
- Extended Length: 160mm (Stroke 100 + Base 60)
- Body Diameter: 22mm (Hexagonal housing)
- Mounting Spacing: 30mm (Center-to-center)
- Seal Material: FKM Fluorocarbon (Standard)/HNBR optional
- Protection Rating: IP67 (Dust/Water resistant)
Corrosion-resistant miniature cylinder engineered for precision linear motion in hostile environments. Features magnetic piston for sensor compatibility and anti-rotation rod design. Requires 40μm filtered air with ISO VG32 oil mist lubrication recommended.
Industrial Applications:
- Pharmaceutical cleanroom actuators
- Marine equipment corrosion zones
- Food processing ejection systems
- Semiconductor wafer handling robots
- High-cycle laboratory automation
Maintenance Alert:
Apply NSF-H1 grease annually for food-grade applications. Avoid side-load exceeding 2N·m.
Use brass fittings to prevent galvanic corrosion.
| Property | Property Value |
|---|---|
| sku | MI16X100R |
| Rear Cover Type | Axial Port Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Bore Diameter | 16mm |
| Stroke | 100mm |
