Airtac MI16-20 Stainless Steel Mini Cylinder MI16X100SCALB
2. Integrated fixed cushion rings on front/rear covers minimize impact during stroke reversal;
3. Multiple rear cover configurations enhance installation flexibility;
4. Crimped roller-clad structure ensures robust connection between stainless steel cylinder barrel and end covers;
5. Full stainless steel construction (piston rod & barrel) provides corrosion resistance for demanding environments;
6. Available in multiple configurations with comprehensive mounting accessories.
Category: Stainless Steel Mini Cylinders | Brand: AirTAC | Series: MI16~20
AirTAC MI16X100SCALB Stainless Steel Mini Cylinder Specifications
- Model: MI16X100SCALB
- Series: MI16~20 stainless steel series
- Bore size: 16mm
- Stroke: 100mm (customizable 1-300mm)
- Operating pressure: 0.15–0.8 MPa
- Temperature range: -20℃ to 150℃
- Material: Stainless steel (SUS304 barrel/piston rod)
- Port size: M5x0.8
- Cushioning: Adjustable cushioning at both ends
- Mounting type: Side flange mounting (SCA series)
- Protection rating: IP65
- Weight: 0.28kg ±2%
- Dimensions: 130mm(L) × 32mm(W) × 32mm(H) (at full extension)
- Rod thread: M6x1 external thread
- Max speed: 500mm/s
- Lubrication: Pre-lubricated (Optional oil-free operation)
Corrosion-resistant stainless steel mini cylinder with space-saving design, featuring precision-ground rod and honed barrel for smooth operation. The LB variant includes enhanced sealing (NBR+PTFE) for high-cycle applications. Maintains consistent performance in humid/chemical environments with 500km+ service life.
- Food processing machinery (washdown environments)
- Pharmaceutical packaging lines
- Semiconductor wafer handling
- Cleanroom automation systems
- Marine equipment actuators
- High-temperature curing oven mechanisms
Installation note:
For vertical mounting, use locknut (ASNU06) to secure piston rod.
Maintain 0.5mm minimum clearance between rod end and load.
Requires 40μm filtration for optimal seal life. Avoid side loads exceeding 2N.
| Property | Property Value |
|---|---|
| sku | MI16X100SCALB |
| Rear Cover Type | Swivel Type |
| Mounting Type | Axial Mounting Bracket |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 16mm |
| Stroke | 100mm |
