Airtac MI16-20 Stainless Steel Mini Cylinder MI16X100SCMLB
2. Integrated fixed cushion rings on front/rear covers minimize impact during stroke reversal;
3. Multiple rear cover configurations enhance installation flexibility;
4. Crimped roller-clad structure ensures robust connection between stainless steel cylinder barrel and end covers;
5. Full stainless steel construction (piston rod & barrel) provides corrosion resistance for demanding environments;
6. Available in multiple configurations with comprehensive mounting accessories.
Category: Stainless Steel Mini Cylinders | Brand: AirTAC | Series: MI16~20
AirTAC MI16X100SCMLB Stainless Steel Mini Cylinder Specifications
- Model Series: MI16~20 series
- Bore size: 16mm
- Stroke: 100mm
- Operation type: Double-acting
- Working pressure: 0.15–0.8 MPa
- Temperature range: -20℃ to 80℃
- Cushion type: Adjustable buffer
- Port size: M5x0.8 (standard pneumatic thread)
- Mounting style: Front flange (MF1 type)
- Rod material: Stainless steel (SUS304)
- Body material: Stainless steel (SUS304)
- Seal material: Heat-resistant NBR
- Protection rating: IP40
- Weight: 0.45kg (excluding accessories)
- Dimensions: 160mm(L) × 32mm(W) × 32mm(H)
- Rod end type: Female thread (M6x1.0)
- Max theoretical thrust: 128N @0.5MPa
- Max speed: 500mm/s
Corrosion-resistant stainless steel mini cylinder designed for precision motion control in compact installations. Features magnetic piston for position sensing compatibility and maintenance-free operation. The hardened piston rod (HRC35-40) ensures durability in high-cycle applications. Optional auto switch models available for feedback systems.
- Cleanroom automation in semiconductor manufacturing
- Pharmaceutical tablet pressing machines
- Food processing equipment (FDA-compliant variants)
- Micro-assembly robotics
- Optical lens positioning systems
- Medical diagnostic instrument actuation
Installation guidelines:
Use anti-vibration washers when mounting to aluminum frames. Lubricate with ISO VG32 hydraulic oil
if operating below -10℃. Maintain 0.5mm minimum clearance between magnetic switch and cylinder body.
Avoid side load exceeding 3N·m.
For vertical installations, use rod lock mechanism during maintenance.
Always install air filter regulator (5μm or finer) upstream.
| Property | Property Value |
|---|---|
| sku | MI16X100SCMLB |
| Rear Cover Type | Round Type |
| Mounting Type | Axial Mounting Bracket |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 16mm |
| Stroke | 100mm |
