Airtac MI16-20 Stainless Steel Mini Cylinder MI16X100SR
2. Integrated fixed cushion rings on front/rear covers minimize impact during stroke reversal;
3. Multiple rear cover configurations enhance installation flexibility;
4. Crimped roller-clad structure ensures robust connection between stainless steel cylinder barrel and end covers;
5. Full stainless steel construction (piston rod & barrel) provides corrosion resistance for demanding environments;
6. Available in multiple configurations with comprehensive mounting accessories.
Category: Stainless Steel Mini Cylinders | Brand: AirTAC | Series: MI16~20
AirTAC MI16X100SR Stainless Steel Mini Cylinder Specifications
- Model Series: MI16~20 (Stainless Steel Series)
- Type: Double-acting cylinder with magnetic piston
- Bore Size: 16 mm
- Stroke: 100 mm (±0.5 mm tolerance)
- Operating Pressure: 0.15–1.0 MPa
- Operating Temperature: -20℃ to 150℃
- Cushioning: Adjustable buffers at both ends
- Mounting Options: Basic front flange, foot mount, or rear clevis
- Port Size: M5x0.8 threaded air ports
- Piston Rod Thread: M6x1.0 external thread
- Material: Stainless steel (SUS304 barrel, SUS303 rod)
- Seal Material: Heat-resistant NBR
- Weight: 0.28 kg (without accessories)
- Dimensions:
- Total Length (L): 136 mm (stroke 100 + base 36)
- Outer Diameter (W): 26 mm
- Height with Foot Mount (H): 42 mm
- IP Rating: IP67 (standard wiper design)
Corrosion-resistant stainless steel construction makes this compact cylinder ideal for harsh environments requiring frequent washdowns or chemical exposure. The magnetic piston enables position sensing with external switches (sensors not included). Features anodized end caps for enhanced wear resistance and optional auto-switch compatibility.
- Food processing machinery (FDA-compliant environments)
- Pharmaceutical packaging lines
- Cleanroom automation systems
- Marine equipment actuators
- Semiconductor wafer handling
Operational note:
Lubricate with ISO VG32 hydraulic oil if used in dry gas systems.
Avoid side loads exceeding 2.5N·m. For vertical mounting,
use counterbalance valves for load-holding applications.
| Property | Property Value |
|---|---|
| sku | MI16X100SR |
| Rear Cover Type | Axial Port Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 16mm |
| Stroke | 100mm |
