Airtac MI16-20 Stainless Steel Mini Cylinder MI16X10CA
2. Integrated fixed cushion rings on front/rear covers minimize impact during stroke reversal;
3. Multiple rear cover configurations enhance installation flexibility;
4. Crimped roller-clad structure ensures robust connection between stainless steel cylinder barrel and end covers;
5. Full stainless steel construction (piston rod & barrel) provides corrosion resistance for demanding environments;
6. Available in multiple configurations with comprehensive mounting accessories.
Category: Stainless Steel Mini Cylinders | Brand: AirTAC | Series: MI16~20
AirTAC MI16X10CA Stainless Steel Mini Cylinder Specifications
- Model: MI16X10CA
- Series: MI16~20 Compact Pneumatic Cylinder
- Bore size: 16mm (0.63")
- Stroke: 10mm (0.39")
- Action type: Double-acting
- Operating pressure: 0.15-0.8 MPa (21.7-116 PSI)
- Temperature range: -10℃ to 150℃
- Port size: M5x0.8 (standard) / NPT1/8 optional
- Cushion type: Adjustable rubber buffer
- Material: Stainless steel (SUS304 body, SUS303 piston rod)
- Mounting type: Front flange threaded (MF1/4 mounting hole)
- Piston rod thread: M6x1.0 (external)
- Weight: 0.15kg (0.33lbs)
- Dimensions:
- Total length (L): 60mm (2.36")
- Body width (W): 20mm (0.79")
- Height with rod (H): 32mm (1.26")
- Seal material: Heat-resistant NBR
- Max theoretical force: 16.1N at 0.5MPa
- ISO standard: 6432 compliant
Ultra-compact corrosion-resistant cylinder with precision-ground rod, designed for high-cycle automation in constrained spaces. Features SUS304 construction for chemical/sterilization resistance and magnetic piston for position sensing. Requires 5μm filtered air with ISO 8573-1 class 3 purity.
- Pharmaceutical tablet press mechanisms
- Semiconductor wafer handling robots
- Food packaging valve actuators
- Laboratory liquid dispensing systems
- Cleanroom conveyor positioning
Installation note:
Apply anti-seize compound on stainless threads. Lubricate with ISO VG32 turbine oil.
Max side load: 1.5N. For vertical mounting, use rod-down orientation to prevent seal wear.
| Property | Property Value |
|---|---|
| sku | MI16X10CA |
| Rear Cover Type | Swivel Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Bore Diameter | 16mm |
| Stroke | <10mm> |
