Airtac MI16-20 Stainless Steel Mini Cylinder MI16X10CATC
2. Integrated fixed cushion rings on front/rear covers minimize impact during stroke reversal;
3. Multiple rear cover configurations enhance installation flexibility;
4. Crimped roller-clad structure ensures robust connection between stainless steel cylinder barrel and end covers;
5. Full stainless steel construction (piston rod & barrel) provides corrosion resistance for demanding environments;
6. Available in multiple configurations with comprehensive mounting accessories.
Category: Stainless Steel Mini Cylinders | Brand: AirTAC | Series: MI16~20
AirTAC MI16X10CATC Stainless Steel Mini Cylinder Technical Details
- Full model: MI16X10CATC
- Series: MI16~20 stainless steel compact cylinders
- Bore size: 16mm (0.63")
- Stroke: 10mm (0.39")
- Operation type: Double-acting
- Operating pressure: 0.05-0.9 MPa
- Medium temperature: -20℃ to 80℃
- Cushioning: Adjustable rubber buffer
- Mounting style: C-type (front flange)
- Port size: M5x0.8 (standard), optional NPT1/8
- Rod material: SUS304 stainless steel
- Body material: SUS303 stainless steel
- Seal material: Fluororubber (FKM)
- Weight: 0.12kg (0.26lbs)
- Dimensions (L×W×H): 60mm×28mm×28mm (2.36"×1.10"×1.10")
- Protection rating: IP67 (dust tight & waterproof)
- Piston speed: 50-700mm/s (lubricated)
Ultra-compact corrosion-resistant actuator with full stainless steel construction, featuring precision-ground rod and low friction seals. The MI series achieves 50% size reduction compared to standard cylinders while maintaining 0.5mm positioning repeatability. Requires ISO VG32 or equivalent oil mist lubrication.
- Cleanroom robotics in semiconductor manufacturing
- Sterile medical device actuators
- Food processing line controls (FDA-compliant)
- High-cycle automation (500+ operations/minute)
- Marine environment pneumatic systems
Installation tip:
Use anti-vibration washers when mounting on aluminum frames. For vertical installations,
maintain minimum 0.3MPa pressure to prevent seal dry-out. Lubricate every 500km of stroke
movement in high-cycling applications.
| Property | Property Value |
|---|---|
| sku | MI16X10CATC |
| Rear Cover Type | Swivel Type |
| Mounting Type | Center Pivot Bracket |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Bore Diameter | 16mm |
| Stroke | <10mm> |
