Airtac MI16-20 Stainless Steel Mini Cylinder MI16X10CM
2. Integrated fixed cushion rings on front/rear covers minimize impact during stroke reversal;
3. Multiple rear cover configurations enhance installation flexibility;
4. Crimped roller-clad structure ensures robust connection between stainless steel cylinder barrel and end covers;
5. Full stainless steel construction (piston rod & barrel) provides corrosion resistance for demanding environments;
6. Available in multiple configurations with comprehensive mounting accessories.
Category: Stainless Steel Mini Cylinders | Brand: AirTAC | Series: MI16~20
AirTAC MI16X10CM Stainless Steel Mini Cylinder Specifications
- Model Series: MI16~20 (Stainless Steel Series)
- Specific Model: MI16X10CM
- Bore Size: 16 mm
- Stroke: 10 mm (±0.5 mm tolerance)
- Operating Pressure: 0.15–0.8 MPa (21.7–116 psi)
- Temperature Range: -20℃ to 150℃
- Port Size: M5x0.8 (Dual auto-switch grooves standard)
- Cushioning: Adjustable rubber buffer (both ends)
- Material: SUS304 stainless steel (rod/body) + NBR seals
- Weight: 0.12 kg (excluding accessories)
- Dimensions (L×W×H):
- Compact Body: 40 mm (retracted length)
- Extended Length: 50 mm (40mm + 10mm stroke)
- Square Body: 16×16 mm profile
- Mounting: Standard foot mounting (2x M4 threaded holes)
- Rod End: M5x0.8 female thread (custom ends available)
- IP Rating: IP65 (standard wiper design)
Ultra-compact corrosion-resistant cylinder with precision-ground rod, designed for harsh environments requiring frequent sterilization or chemical exposure. Features dual-position magnetic sensor slots (inductive sensor compatible) and self-lubricating bushings. Operates at ≤1.5 m/s piston speed for smooth motion control.
- Food processing/packaging machinery (washdown environments)
- Pharmaceutical tablet press automation
- Semiconductor wafer handling robots
- Medical device actuation systems
- Cleanroom positioning mechanisms
Installation Tips:
Use with guided rail systems for lateral force prevention. Lubricate with ISO VG32 hydraulic oil if used below -10℃. Maximum side load: 1.5N·m. For vacuum applications, specify V-type seal variant.
| Property | Property Value |
|---|---|
| sku | MI16X10CM |
| Rear Cover Type | Round Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Bore Diameter | 16mm |
| Stroke | <10mm> |
