Airtac MI16-20 Stainless Steel Mini Cylinder MI16X10SCM
2. Integrated fixed cushion rings on front/rear covers minimize impact during stroke reversal;
3. Multiple rear cover configurations enhance installation flexibility;
4. Crimped roller-clad structure ensures robust connection between stainless steel cylinder barrel and end covers;
5. Full stainless steel construction (piston rod & barrel) provides corrosion resistance for demanding environments;
6. Available in multiple configurations with comprehensive mounting accessories.
Category: Stainless Steel Mini Cylinders | Brand: AirTAC | Series: MI16~20
AirTAC MI16X10SCM Stainless Steel Mini Cylinder Specifications
- Model Series: MI16~20 (16mm bore size variant)
- Bore Diameter: 16mm
- Stroke: 10mm (±0.5mm tolerance)
- Material: SUS304 stainless steel (rod & tube)
- Operating Pressure: 0.05–0.8 MPa
- Operating Temperature: -20℃ to 150℃
- Medium: Dry air (Lubricated air requires oil mist separator)
- Cushioning: Adjustable rubber buffer (both ends)
- Mounting Style: Front flange/Foot mount (MF1 type)
- Port Size: M5x0.8 threaded (standard dual ports)
- Rod End Thread: M6x1 male thread
- Weight: 250g ±5% (including mounting accessories)
- Dimensions: 60mm(L) × 40mm(W) × 40mm(H) (at full retraction)
- Piston Speed: 50–800 mm/s (optimal range)
- Seal Material: Heat-resistant NBR with PTFE coating
- ISO Standard: Compliant with ISO 6432:2015
Ultra-compact corrosion-resistant cylinder designed for precision motion in harsh environments. Features enhanced side load resistance through integrated guide slots and dual piston seals. Requires minimal lubrication (1 drop of ISO VG32 oil per 1 million cycles recommended). Includes anti-rotation mechanism for stable tooling applications.
- Pharmaceutical capsule filling machines
- Semiconductor wafer handling robots
- Food packaging line actuators
- Marine equipment control systems
- High-temperature sterilization chambers
Installation note:
Use copper-free anti-seize compound on threads in saltwater environments.
Maximum allowable lateral load: 15N at mid-stroke. For vertical mounting,
add 20% safety factor to thrust calculations.
| Property | Property Value |
|---|---|
| sku | MI16X10SCM |
| Rear Cover Type | Round Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 16mm |
| Stroke | <10mm> |
