Airtac MI16-20 Stainless Steel Mini Cylinder MI16X10SCMLB
$27.88
Regular price
$35.38
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
MI16X10SCMLB
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Compliant with ISO 6432 standard (Bore sizes: 8-25mm);
2. Integrated fixed cushion rings on front/rear covers minimize impact during stroke reversal;
3. Multiple rear cover configurations enhance installation flexibility;
4. Crimped roller-clad structure ensures robust connection between stainless steel cylinder barrel and end covers;
5. Full stainless steel construction (piston rod & barrel) provides corrosion resistance for demanding environments;
6. Available in multiple configurations with comprehensive mounting accessories.
Category: Stainless Steel Mini Cylinders | Brand: AirTAC | Series: MI16~20
Installation tips:
Use anti-seize compound on stainless threads. Lubricate with ISO VG32 turbine oil.
Maintain 0.5mm minimum clearance between magnetic sensor and cylinder body. Avoid side-load exceeding 15N.
2. Integrated fixed cushion rings on front/rear covers minimize impact during stroke reversal;
3. Multiple rear cover configurations enhance installation flexibility;
4. Crimped roller-clad structure ensures robust connection between stainless steel cylinder barrel and end covers;
5. Full stainless steel construction (piston rod & barrel) provides corrosion resistance for demanding environments;
6. Available in multiple configurations with comprehensive mounting accessories.
Category: Stainless Steel Mini Cylinders | Brand: AirTAC | Series: MI16~20
AirTAC MI16X20SCMLB Stainless Steel Mini Cylinder Specifications
- Full model: MI16X10SCMLB (Base model MI16~20 series)
- Bore size: 16mm
- Stroke: 10mm (adjustable cushion)
- Material: SUS304 stainless steel body/piston rod
- Operating pressure: 0.15-0.8 MPa
- Temperature range: -20℃ to 150℃
- Port size: M5x0.8 (dual auto switch grooves)
- Piston speed: 50-800 mm/s
- Mounting style: Front flange/Foot (optional accessories)
- Rod end type: Male thread M6x1.0
- Buffer type: Rubber cushion (both ends)
- Seal material: Fluororubber (FKM) for high temp resistance
- Weight: 0.22 kg (bare cylinder)
- Dimensions: 56mm(L) × 25mm(W) × 25mm(H)
- ISO standard: 6432 compliant
- Protection rating: IP67 (dust/water resistant)
Corrosion-resistant mini cylinder with medical-grade surface finish (Ra≤0.4μm), featuring double O-ring seals for leak-proof operation. Includes magnetic piston for sensor compatibility. Designed for 1 million+ cycle durability under continuous operation.
Ideal for:
- Cleanroom automation (semiconductor/FPCB handling)
- Food processing machinery (washdown environments)
- Pharmaceutical tablet pressing systems
- Marine equipment actuators
- High-cycle textile machinery
Installation tips:
Use anti-seize compound on stainless threads. Lubricate with ISO VG32 turbine oil.
Maintain 0.5mm minimum clearance between magnetic sensor and cylinder body. Avoid side-load exceeding 15N.
Common accessories:
MFH-5 mini flow control valve, SNS-M8 magnetic sensor,
MIF16-10S mounting bracket (sold separately)
| Property | Property Value |
|---|---|
| sku | MI16X10SCMLB |
| Rear Cover Type | Round Type |
| Mounting Type | Axial Mounting Bracket |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 16mm |
| Stroke | <10mm> |
