Airtac MI16-20 Stainless Steel Mini Cylinder MI16X10SR
2. Integrated fixed cushion rings on front/rear covers minimize impact during stroke reversal;
3. Multiple rear cover configurations enhance installation flexibility;
4. Crimped roller-clad structure ensures robust connection between stainless steel cylinder barrel and end covers;
5. Full stainless steel construction (piston rod & barrel) provides corrosion resistance for demanding environments;
6. Available in multiple configurations with comprehensive mounting accessories.
Category: Stainless Steel Mini Cylinders | Brand: AirTAC | Series: MI16~20
AirTAC MI16X10SR Stainless Steel Miniature Cylinder Specifications
- Series: MI16~20 Stainless Steel Mini Cylinder
- Full model: MI16X10SR
- Action type: Single-acting (spring return)
- Bore size: 16mm
- Stroke: 10mm (±0.5mm)
- Operating pressure: 0.1-1.0 MPa
- Temperature range: -10℃ to 150℃
- Port size: M5×0.8 (standard) with NPT1/8 adapter optional
- Cushioning: Fixed cushion (non-adjustable)
- Material: SUS304 stainless steel barrel/end caps
- Seal material: Fluororubber (FKM) for high temp resistance
- Mounting types: Basic foot mount (MF1), other brackets optional
- Piston speed: 50-700 mm/s (optimal range 100-300 mm/s)
- Weight: 0.23 kg (excluding accessories)
- Dimensions:
- Length: 80mm (retracted)
- Width: 32mm (including mounting tabs)
- Height: 32mm (square body profile)
Corrosion-resistant miniature cylinder with FDA-compliant seals, designed for precision linear motion in harsh environments. Features a compact square body for space-constrained installations and permanent lubrication for maintenance-free operation. Requires 40μm filtered air with recommended ISO VG32 hydraulic oil mist lubrication (0.3-0.5cc/min).
- Food processing equipment actuators
- Pharmaceutical capsule filling machines
- Semiconductor wafer handling systems
- Marine environment control mechanisms
- High-temperature sterilization devices
Installation guidelines:
Use anti-rotation brackets (AR series) for torque-sensitive applications.
Maintain 0.5mm minimum lateral clearance during alignment.
Apply thread sealant on port connections (PTFE tape not recommended).
Avoid side load exceeding 3N·m.
For vertical mounting, reduce payload capacity by 30%.
Cycle rate should not exceed 85% of calculated maximum (15,000 cycles/day).
| Property | Property Value |
|---|---|
| sku | MI16X10SR |
| Rear Cover Type | Axial Port Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 16mm |
| Stroke | <10mm> |
