Airtac MI16-20 Stainless Steel Mini Cylinder MI16X10SU
2. Integrated fixed cushion rings on front/rear covers minimize impact during stroke reversal;
3. Multiple rear cover configurations enhance installation flexibility;
4. Crimped roller-clad structure ensures robust connection between stainless steel cylinder barrel and end covers;
5. Full stainless steel construction (piston rod & barrel) provides corrosion resistance for demanding environments;
6. Available in multiple configurations with comprehensive mounting accessories.
Category: Stainless Steel Mini Cylinders | Brand: AirTAC | Series: MI16~20
AirTAC MI16X10SU Stainless Steel Mini Cylinder Specifications
- Series: MI16~20 Compact Cylinder Series
- Model: MI16X10SU
- Bore Size: 16mm
- Stroke: 10mm (±0.5mm tolerance)
- Structure: Single-acting spring return
- Material: Stainless steel (SUS304 barrel/piston rod)
- Seal Material: NBR (Nitrile rubber) with PTFE wear rings
- Operating Pressure: 0.15-0.8 MPa
- Operating Temperature: -20℃ to 80℃
- Cushioning: Adjustable rubber buffer
- Port Size: M5x0.8 threaded (Standard dual ports)
- Weight: 0.18kg (Without accessories)
- Dimensions:
- Total Length (L): 60mm (Stroke extended)
- Body Width (W): 20mm
- Mounting Height (H): 16.5mm
- Rod Thread: M6x1.0 external thread
- IP Rating: IP65 (Dust-tight & water jet protected)
- Lubrication: Grease pre-lubricated (Non-replenishing design)
Ultra-compact stainless steel cylinder designed for corrosive environments and precision motion control. Features double-sealed construction with self-compensating wear bands for maintenance-free operation. The chromium-plated piston rod provides exceptional resistance to chemical exposure and mechanical wear. Requires 40μm filtered air and compatible with ISO 6432 mounting accessories.
- Pharmaceutical packaging line actuators
- Food processing equipment (NSF-compliant)
- Semiconductor wafer handling robots
- Marine instrumentation controls
- Cleanroom automation systems
Installation note:
Maximum side load ≤1.5N. Use floating brackets for alignment-sensitive applications.
Avoid lateral forces exceeding 20% of thrust capacity. For vertical mounting,
position rod end downward to prevent condensate ingress.
| Property | Property Value |
|---|---|
| sku | MI16X10SU |
| Rear Cover Type | Radial Air Inlet |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 16mm |
| Stroke | <10mm> |
