Airtac MI25~40 Stainless Steel Mini Cylinder MI25X100CA
2. Integrated shock-absorbing pads on front/rear covers mitigate impact during direction changes;
3. Multiple rear cover configurations enhance installation flexibility;
4. Crimped and rolled structure ensures robust connection between stainless steel cylinder barrel and end covers;
5. Stainless steel piston rods and cylinders provide corrosion resistance for harsh operating environments;
6. Comprehensive range of specifications and mounting accessories available for customized solutions.
Category: Stainless Steel Mini Cylinders | Brand: AIRTAC | Series: MI25~40
AirTAC MI25X100CA Stainless Steel Mini Cylinder Specifications
- Model: MI25X100CA
- Series: MI25~40 Compact Cylinder Family
- Bore size: 25 mm
- Stroke: 100 mm
- Operation: Double-acting
- Material: Stainless steel body (SUS304), NBR seals
- Operating pressure: 0.05–1.0 MPa
- Temperature range: -20℃ to 150℃
- Cushioning: Adjustable rubber buffer (both ends)
- Port size: M5x0.8 (Standard), optional G1/8
- Mounting type: Front flange (MF series compatible)
- Rod rotation: Prevented
- Weight: 520 g ±2% (with standard fittings)
- Dimensions:
- Length (retracted): 136 mm
- Body diameter: 32 mm
- Stroke tolerance: +1.5 mm
- Rod thread: M6x1.0
- Protection rating: IP67 (dust/water resistant)
- Lubrication: Pre-lubricated (Grease-free operation available)
Corrosion-resistant mini cylinder engineered for harsh environments requiring frequent washdowns or chemical exposure. Features a space-saving design with 50% reduced footprint compared to standard ISO cylinders. The electropolished surface minimizes particle adhesion, making it ideal for cleanroom applications. Includes anti-vibration pads for noise reduction (75 dB max).
- Pharmaceutical tablet pressing machines
- Semiconductor wafer handling robots
- Food packaging line actuators
- Marine equipment hatch controls
- High-temperature sterilization chambers
Installation note:
Use stainless steel fasteners to prevent galvanic corrosion.
For full stroke operation, maintain 0.5 MPa minimum pressure.
Lubricate rod every 500km stroke (use ISO VG32 hydraulic oil).
| Property | Property Value |
|---|---|
| sku | MI25X100CA |
| Rear Cover Type | Swivel Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <25 mm> |
| Stroke | 100mm |
