Airtac MI25~40 Stainless Steel Mini Cylinder MI25X100SCA
2. Integrated shock-absorbing pads on front/rear covers mitigate impact during direction changes;
3. Multiple rear cover configurations enhance installation flexibility;
4. Crimped and rolled structure ensures robust connection between stainless steel cylinder barrel and end covers;
5. Stainless steel piston rods and cylinders provide corrosion resistance for harsh operating environments;
6. Comprehensive range of specifications and mounting accessories available for customized solutions.
Category: Stainless Steel Mini Cylinders | Brand: AIRTAC | Series: MI25~40
AirTAC MI25X100SCA Stainless Steel Mini Cylinder Specifications
- Model: MI25X100SCA
- Series: MI25~40 Compact Cylinder Range
- Bore size: 25mm (40mm max in series)
- Stroke: 100mm (Customizable: 25-300mm)
- Material: SUS304 Stainless Steel (Body/Rod)
- Operating pressure: 0.15–0.8 MPa
- Temperature range: -20℃ to 80℃ (NBR seals)
- Port size: M5x0.8 (Dual 2-port design)
- Cushioning: Adjustable rubber buffer
- Mounting type: Standard MF1 foot mounting
- Protection rating: IP65 (Dust/water jet resistant)
- Weight: 0.82kg ±3% (Without accessories)
- Dimensions:
- Extended length: 160mm (Stroke+60mm)
- Body diameter: 35mm (Max outer dimension)
- Rod thread: M6x1.0 (External)
- Mounting hole spacing: 20mm (Vertical) × 30mm (Horizontal)
Corrosion-resistant mini cylinder with 30% reduced footprint vs standard models. Features dual anti-rotation guide slots and chromium-plated piston rod (3μm thickness) for precise linear motion. Compatible with ISO 6432 mounting accessories. Requires 40μm filtered air with 1-3 drops of ISO VG32 oil per 10L air volume.
- Cleanroom automation (pharmaceutical/medical)
- Food processing machinery (washdown environments)
- Semiconductor wafer handling robots
- Marine equipment actuators
- High-cycle packaging systems (10M+ life cycles)
Operation tip:
Maintain 0.3-0.5MPa pressure during initial run-in (first 500 cycles).
For vertical mounting, use locking nuts on piston rod threads.
| Property | Property Value |
|---|---|
| sku | MI25X100SCA |
| Rear Cover Type | Swivel Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <25 mm> |
| Stroke | 100mm |
