Airtac MI25~40 Stainless Steel Mini Cylinder MI25X105CA
2. Integrated shock-absorbing pads on front/rear covers mitigate impact during direction changes;
3. Multiple rear cover configurations enhance installation flexibility;
4. Crimped and rolled structure ensures robust connection between stainless steel cylinder barrel and end covers;
5. Stainless steel piston rods and cylinders provide corrosion resistance for harsh operating environments;
6. Comprehensive range of specifications and mounting accessories available for customized solutions.
Category: Stainless Steel Mini Cylinders | Brand: AIRTAC | Series: MI25~40
AirTAC MI25X40 Series Stainless Steel Mini Cylinder - MI25X105CA Specifications
- Model Code: MI25X105CA
- Bore Size: 25mm
- Stroke: 105mm
- Operating Pressure: 0.05-0.8 MPa
- Ambient Temperature: -20℃ to 80℃
- Cushion Type: Adjustable air cushion (both ends)
- Mounting Style: Basic type (optional front/rear flange kits)
- Material: SUS304 stainless steel body
- Seal Material: NBR/FKM optional
- Port Size: M5x0.8 (standard), G1/8 optional
- Weight: 0.82kg (bare cylinder)
- Dimensions: 180mm(L) × 25mm(W) × 25mm(H)
- Rod Thread: M6x1.0 internal thread
- Protection Class: IP40 (IP67 with special seals)
- Piston Speed: 50-800mm/s (optimal range)
Corrosion-resistant stainless steel mini cylinder designed for precision linear motion in harsh environments. Features chrome-plated piston rod (SUS420J2) for enhanced wear resistance and optional FKM seals for chemical compatibility. The compact design incorporates dual adjustable air cushions to minimize end-impact noise.
- Food processing equipment (FDA-compliant variants)
- Medical device actuation systems
- Cleanroom automation in semiconductor manufacturing
- Marine environment control mechanisms
- Pharmaceutical packaging lines
Installation Note:
Lubricate with ISO VG32 turbine oil if used without built-in lubricator.
Maximum side load: 5N at full extension. For vertical mounting,
use locking nut (AN6 specification) on piston rod end.
- Seal replacement: 5 million cycles (NBR) / 8 million cycles (FKM)
- Rod lubrication: Every 3 months in continuous operation
- Air filter maintenance: 0.3μm filter required, element change every 500hrs
| Property | Property Value |
|---|---|
| sku | MI25X105CA |
| Rear Cover Type | Swivel Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <25 mm> |
| Stroke | 105mm |
