Airtac MI25~40 Stainless Steel Mini Cylinder MI25X105SCA
2. Integrated shock-absorbing pads on front/rear covers mitigate impact during direction changes;
3. Multiple rear cover configurations enhance installation flexibility;
4. Crimped and rolled structure ensures robust connection between stainless steel cylinder barrel and end covers;
5. Stainless steel piston rods and cylinders provide corrosion resistance for harsh operating environments;
6. Comprehensive range of specifications and mounting accessories available for customized solutions.
Category: Stainless Steel Mini Cylinders | Brand: AIRTAC | Series: MI25~40
AirTAC MI25X105SCA Stainless Steel Mini Cylinder Specifications
- Model: MI25X105SCA
- Series: MI25~40 Compact Cylinder Line
- Bore Size: 25mm
- Stroke: 105mm
- Operating Pressure: 0.05–0.8 MPa
- Material: Stainless Steel (SUS304 body/piston rod)
- Buffer Type: Adjustable Cushioning (Dual-side)
- Mounting Options: Front Flange (Standard), Rear Flange, Foot Mount
- Port Size: M5x0.8 (Dual ports)
- Temperature Range: -20℃ to 80℃
- Protection Rating: IP65 (Dust/Water Resistant)
- Weight: 0.68kg (Excluding accessories)
- Dimensions: 180mm(L) × 30mm(W) × 30mm(H)
Corrosion-resistant stainless steel cylinder optimized for precision linear motion in confined spaces. Features dual adjustable rubber buffers for smooth end-stroke deceleration and magnetic piston for position sensing compatibility. The compact MI series delivers 23N thrust at 0.5MPa with ≤0.5mm/100mm stroke deviation.
- Cleanroom automation systems (semiconductor/medical)
- Food processing machinery (washdown environments)
- Pharmaceutical tablet press actuators
- Robotic end-effector positioning
- Laboratory liquid handling devices
Installation Best Practices:
Use PTFE-based lubricant on rod seals for high-cycle applications.
Maintain 0.5mm minimum lateral clearance during alignment.
For vertical mounting, install with piston rod facing downward
to prevent condensate accumulation.
| Property | Property Value |
|---|---|
| sku | MI25X105SCA |
| Rear Cover Type | Swivel Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <25 mm> |
| Stroke | 105mm |
