Airtac MI25~40 Stainless Steel Mini Cylinder MI25X10SCA
2. Integrated shock-absorbing pads on front/rear covers mitigate impact during direction changes;
3. Multiple rear cover configurations enhance installation flexibility;
4. Crimped and rolled structure ensures robust connection between stainless steel cylinder barrel and end covers;
5. Stainless steel piston rods and cylinders provide corrosion resistance for harsh operating environments;
6. Comprehensive range of specifications and mounting accessories available for customized solutions.
Category: Stainless Steel Mini Cylinders | Brand: AIRTAC | Series: MI25~40
AirTAC MI25X10SCA Stainless Steel Mini Cylinder Specifications
- Model Series: MI25~40 (MI25X10SCA specific)
- Type: Single-acting spring return (push type)
- Bore size: 25mm
- Stroke: 10mm (±1mm tolerance)
- Operating pressure: 0.05-1.0 MPa
- Operating medium: Dry air (ISO8573-1:2010 Class 3)
- Temperature range: -20℃ to 150℃ (continuous use ≤80℃)
- Cushioning: Adjustable rubber buffer
- Mounting type: Front flange (SCA series)
- Port size: M5x0.8 (Dual 2-port)
- Seal material: HNBR (Hydrogenated Nitrile)
- Material: SUS304 stainless steel (body/piston rod)
- Weight: 0.25kg ±3%
- Dimensions:
- Body length: 56mm
- Extended length: 66mm (stroke included)
- Width: 34mm (mounting flange to rod end)
- Height: 34mm (including mounting protrusions)
- Rod thread: M6x1.0 (external)
- Protection rating: IP67 (rod extended)
Corrosion-resistant mini actuator with precision-ground rod, designed for clean environments requiring frequent washdowns. Features low-friction seals rated for 2,000km travel life and anti-rotation piston design. Requires 5-40μm filtered air with ISO VG32 turbine oil mist lubrication (1:1000 ratio).
- Pharmaceutical tablet press ejection systems
- Semiconductor wafer handling robots
- Food packaging machine stopper actuators
- Cleanroom conveyor positioning
- Laboratory automation sample pushers
Installation note:
Maximum side load 3.5N at full extension. For vertical mounting,
use spring-side down orientation. Lubricate every 6 months under
normal operation (500 cycles/day).
| Property | Property Value |
|---|---|
| sku | MI25X10SCA |
| Rear Cover Type | Swivel Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <25 mm> |
| Stroke | <10mm> |
