Airtac MI25~40 Stainless Steel Mini Cylinder MI25X10SCM
2. Integrated shock-absorbing pads on front/rear covers mitigate impact during direction changes;
3. Multiple rear cover configurations enhance installation flexibility;
4. Crimped and rolled structure ensures robust connection between stainless steel cylinder barrel and end covers;
5. Stainless steel piston rods and cylinders provide corrosion resistance for harsh operating environments;
6. Comprehensive range of specifications and mounting accessories available for customized solutions.
Category: Stainless Steel Mini Cylinders | Brand: AIRTAC | Series: MI25~40
AirTAC MI25X40 Stainless Steel Miniature Cylinder MI25X10SCM Technical Details
- Model Series: MI25~40 Compact Cylinder Line
- Specific Model: MI25X10SCM
- Bore Size: 25mm (Standard)
- Stroke: 10mm (Customizable up to 40mm)
- Material: SUS304 Stainless Steel Body
- Operating Pressure: 0.05-1.0 MPa
- Temperature Range: -20℃ to 150℃
- Cushioning: Adjustable Rubber Bumper
- Mounting Style: Basic Front Flange (MFI)
- Port Size: M5x0.8 (Dual Ports)
- Piston Rod Thread: M6x1.0
- Max Speed: 500 mm/s
- Protection Rating: IP67 (Standard wipes)
- Weight: 0.23 kg ±5% (Without accessories)
- Dimensions:
- Length: 65mm (Stroke 10mm version)
- Width: 32mm (Flange mounting base)
- Height: 25mm (Cylinder diameter)
Corrosion-resistant miniature cylinder featuring laser-engraved identification marks and PTFE-impregnated seals. Optimized for high-cycle applications requiring washdown compatibility (NSF compliant). Features integrated mounting slots for tool-free sensor installation. Requires ISO 8573-1:2010 Class 3-4-3 compressed air.
- Pharmaceutical tablet press ejection systems
- Cleanroom wafer handling robots
- Food packaging machine clamp actuators
- Marine equipment controls
- 3D printer automatic bed leveling
Maintenance advisory:
Lubricate with ISO VG32 hydraulic oil monthly in high-humidity environments.
Avoid side-load exceeding 2N·m during installation. Magnetic versions (MI25X10SCM-M)
available for position feedback integration.
| Property | Property Value |
|---|---|
| sku | MI25X10SCM |
| Rear Cover Type | Round Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <25 mm> |
| Stroke | <10mm> |
