Airtac MI25~40 Stainless Steel Mini Cylinder MI25X10U
2. Integrated shock-absorbing pads on front/rear covers mitigate impact during direction changes;
3. Multiple rear cover configurations enhance installation flexibility;
4. Crimped and rolled structure ensures robust connection between stainless steel cylinder barrel and end covers;
5. Stainless steel piston rods and cylinders provide corrosion resistance for harsh operating environments;
6. Comprehensive range of specifications and mounting accessories available for customized solutions.
Category: Stainless Steel Mini Cylinders | Brand: AIRTAC | Series: MI25~40
AirTAC MI25X40 Stainless Steel Mini Cylinder MI25X10U Technical Details
- Series: MI25~40 Stainless Steel Mini Series
- Bore size: 25mm (Standard: 25/32/40mm options)
- Stroke: 10mm (Customizable 1-100mm)
- Material: SUS304 stainless steel body + aluminum alloy end caps
- Rod thread: M5×0.8 external thread (standard)
- Operating pressure: 0.05-1.0 MPa
- Temperature range: -20℃ to 150℃
- Cushioning: Adjustable pneumatic cushion + shock absorber pad
- Port size: M5×0.8 (G1/8 optional)
- Weight: 0.32kg (bare cylinder), 0.38kg with accessories
- Dimensions: 98mm(L) × 25mm(W) × 25mm(H)
- Seal material: Fluororubber (FKM) for high temp resistance
- Repeat accuracy: ±0.1mm
- Max speed: 500mm/s
- ISO certification: 6431/15552 compliant
Corrosion-resistant mini cylinder optimized for harsh environments, featuring a compact 25mm square profile for space-constrained installations. The chrome-plated piston rod integrates wear-resistant technology, supporting 2 million cycles at rated load. Requires ISO 8573-1:2010 class 4 compressed air.
- Pharmaceutical capsule filling machines (sanitary requirements)
- Semiconductor wafer handling robots
- Marine equipment actuators (saltwater resistant)
- High-temperature textile curing presses
- 3D printer automatic bed leveling systems
Maintenance tip:
Lubricate with ISO VG32 hydraulic oil monthly in continuous operation.
Avoid side load exceeding 3N·m. For vertical mounting, use anti-drop lock nut (MI-AD25 accessory).
| Property | Property Value |
|---|---|
| sku | MI25X10U |
| Rear Cover Type | Radial Air Inlet |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <25 mm> |
| Stroke | <10mm> |
