Airtac MI8~12 Stainless Steel Mini Cylinder MI10X100U
$19.30
Regular price
$26.80
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
MI10X100U
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Compliant with ISO 6432 standard (Bore sizes M8~M25);
2. Integrated cushion rings on front/rear caps to mitigate impact during directional changes;
3. Multiple rear cap configurations for enhanced mounting flexibility;
4. Crimped and rolled structure securely connects stainless steel cylinder body with end caps;
5. Stainless steel construction (piston rod & cylinder) ensures corrosion resistance in moderately corrosive environments;
6. Comprehensive model variants and mounting accessories available upon request.
Category: Stainless Steel Mini Cylinders | Brand: AIRTAC | Series: MI8~12
Installation tip:
For vertical mounting, reduce max load to 70% of horizontal capacity.
Use PTFE tape on ports - do not overtighten (max 1.5Nm torque).
Maintenance note:
Flush with deionized water weekly in saltwater environments.
Avoid silicone-based lubricants to prevent seal degradation.
2. Integrated cushion rings on front/rear caps to mitigate impact during directional changes;
3. Multiple rear cap configurations for enhanced mounting flexibility;
4. Crimped and rolled structure securely connects stainless steel cylinder body with end caps;
5. Stainless steel construction (piston rod & cylinder) ensures corrosion resistance in moderately corrosive environments;
6. Comprehensive model variants and mounting accessories available upon request.
Category: Stainless Steel Mini Cylinders | Brand: AIRTAC | Series: MI8~12
AirTAC MI10X100U Stainless Steel Mini Cylinder Specifications
- Model: MI10X100U (MI Series Compact Cylinder)
- Bore size: 10mm (MI8~12 series available)
- Stroke: 100mm (customizable 5-300mm)
- Material: SUS304 stainless steel body, NBR seals
- Operating pressure: 0.05-1.0 MPa
- Temperature range: -20℃ to 150℃
- Cushioning: Adjustable rubber buffer
- Mounting type: Basic foot mount (MF1), optional side/axial mounts
- Port size: M5x0.8 (standard), G1/8 optional
- Piston rod thread: M5x0.8 (6mm rod diameter)
- Max speed: 500 mm/s (with cushion)
- Weight: 0.25 kg (excluding accessories)
- Dimensions: 130mm(L) x 28mm(W) x 28mm(H)
- Protection rating: IP67 (dust/water resistant)
- Lubrication: Pre-lubricated (use ISO VG32 oil if maintained)
Ultra-compact corrosion-resistant cylinder with precision-ground rod for smooth operation in harsh environments. Features dual anti-rotation design for stable linear motion and magnetic piston for position sensing compatibility. Requires 40μm filtered air.
Typical Applications:
- Semiconductor wafer handling robots
- Food packaging machinery (NSF compliant)
- Pharmaceutical tablet presses
- Underwater sensor positioning systems
- 3D printer automated bed leveling
Installation tip:
For vertical mounting, reduce max load to 70% of horizontal capacity.
Use PTFE tape on ports - do not overtighten (max 1.5Nm torque).
Maintenance note:
Flush with deionized water weekly in saltwater environments.
Avoid silicone-based lubricants to prevent seal degradation.
| Property | Property Value |
|---|---|
| sku | MI10X100U |
| Rear Cover Type | Radial Air Inlet |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Bore Diameter | <10mm> |
| Stroke | 100mm |
