Airtac MI8~12 Stainless Steel Mini Cylinder MI10X10CATC
2. Integrated cushion rings on front/rear caps to mitigate impact during directional changes;
3. Multiple rear cap configurations for enhanced mounting flexibility;
4. Crimped and rolled structure securely connects stainless steel cylinder body with end caps;
5. Stainless steel construction (piston rod & cylinder) ensures corrosion resistance in moderately corrosive environments;
6. Comprehensive model variants and mounting accessories available upon request.
Category: Stainless Steel Mini Cylinders | Brand: AIRTAC | Series: MI8~12
AirTAC MI10X10CATC Stainless Steel Mini Cylinder Specifications
- Model Series: MI8~12 (MI10 variant)
- Bore Size: 10 mm
- Stroke: 10 mm
- Operation Type: Double-acting (air ports on both ends)
- Operating Pressure: 0.15–1.0 MPa
- Temperature Range: -20℃ to 80℃
- Port Size: M5x0.8 (standard pneumatic thread)
- Cushioning: Adjustable rubber buffer (both ends)
- Material:
- Cylinder Barrel: SUS304 stainless steel
- Piston Rod: SUS303 stainless steel
- Seals: NBR (Nitrile) with grease retention design
- Weight: 0.25 kg (without accessories)
- Dimensions:
- Total Length (L): 50 mm (at mid-stroke position)
- Body Width (W): 20 mm
- Height (H): 20 mm (excluding mounting hardware)
- Rod Thread: M4x0.7 (front end)
- IP Rating: IP67 (dust-tight & protected against immersion)
- Lubrication: Pre-lubricated (maintenance-free for 2000 km operation)
Ultra-compact stainless steel cylinder engineered for corrosive environments and precision linear motion. Features a self-aligning piston design that compensates for minor misalignment (max ±2°). The magnetic piston version (MI10X10CATCM) enables position sensing compatibility. Operates at speeds up to 1.5 m/s with proper cushioning adjustment.
- Cleanroom robotics in semiconductor manufacturing
- Sterilization equipment actuators in medical facilities
- Marine environment automation systems
- Food packaging machinery (FDA-compliant grease option available)
- High-cycle CNC tool changers (500K+ cycle rating)
Installation Guidelines:
Use only with filtered air (5μm+ filter). For vertical mounting,
add 10% extra force margin. Avoid side load exceeding 3N.
Break-in period: Operate at 0.3 MPa for 50 cycles before full load use.
| Property | Property Value |
|---|---|
| sku | MI10X10CATC |
| Rear Cover Type | Swivel Type |
| Mounting Type | Center Pivot Bracket |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Bore Diameter | <10mm> |
| Stroke | <10mm> |
