Airtac MI8~12 Stainless Steel Mini Cylinder MI10X10SU
2. Integrated cushion rings on front/rear caps to mitigate impact during directional changes;
3. Multiple rear cap configurations for enhanced mounting flexibility;
4. Crimped and rolled structure securely connects stainless steel cylinder body with end caps;
5. Stainless steel construction (piston rod & cylinder) ensures corrosion resistance in moderately corrosive environments;
6. Comprehensive model variants and mounting accessories available upon request.
Category: Stainless Steel Mini Cylinders | Brand: AIRTAC | Series: MI8~12
AirTAC MI10X10SU Stainless Steel Miniature Cylinder Specifications
- Series: MI8~12 stainless steel compact cylinder
- Model: MI10X10SU
- Bore size: 10mm
- Stroke: 10mm (±1mm)
- Operating pressure: 0.05–1.0 MPa
- Ambient temperature: -20℃ to 80℃
- Port size: M5×0.8 (dual ports)
- Cushioning: Rubber buffer (both ends)
- Piston speed: 50–700 mm/s
- Mounting type: Basic (no built-in mounts)
- Material: SUS304 stainless steel body, NBR seals
- Weight: 85g ±2g
- Dimensions:
- Length: 62mm (full retract)
- Width: 20mm (body diameter)
- Height: 28mm (including rod end)
- Rod thread: M5×0.8 external thread
- Protection rating: IP67 (standard wiper)
Corrosion-resistant miniature cylinder with ultra-compact profile, featuring medical-grade surface finish (Ra≤0.8μm). Optimized for clean environments requiring frequent washdowns or chemical exposure. Includes magnetic piston for position sensing compatibility (sensor not included). Requires 5μm filtered air with ISO 8573-1:2010 Class 3.4.3 purity.
- Pharmaceutical tablet pressing mechanisms
- Semiconductor wafer handling robots
- Food packaging line actuators
- Endoscope sterilization equipment
- Cleanroom conveyor systems
Installation tip:
Use anti-rotation brackets (ASNU10-01 accessory recommended) when
implementing angular movements. Lubricate with ISO VG32 hydraulic oil
if operating below -10℃.
| Property | Property Value |
|---|---|
| sku | MI10X10SU |
| Rear Cover Type | Radial Air Inlet |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | <10mm> |
| Stroke | <10mm> |
