Airtac MI8~12 Stainless Steel Mini Cylinder MI10X10SUH
2. Integrated cushion rings on front/rear caps to mitigate impact during directional changes;
3. Multiple rear cap configurations for enhanced mounting flexibility;
4. Crimped and rolled structure securely connects stainless steel cylinder body with end caps;
5. Stainless steel construction (piston rod & cylinder) ensures corrosion resistance in moderately corrosive environments;
6. Comprehensive model variants and mounting accessories available upon request.
Category: Stainless Steel Mini Cylinders | Brand: AIRTAC | Series: MI8~12
AirTAC MI10X10SUH Stainless Steel Mini Cylinder Specifications
- Series: MI8~12 Compact Cylinder Line
- Model: MI10X10SUH
- Bore size: 10mm
- Stroke: 10mm (±1mm)
- Material: SUS304 Stainless Steel (Body/Rod)
- Operating pressure: 0.15–1.0 MPa
- Temperature range: -20℃ to 150℃
- Cushion type: Adjustable air cushion
- Port thread: M5×0.8 (Standard dual ports)
- Rod end: M4×0.7 external thread
- Seal material: NBR/FKM optional
- Weight: 0.24kg (NBR seals) / 0.25kg (FKM seals)
- Dimensions: 60mm(L) × 20mm(W) × 20mm(H)
- Mounting type: Basic (no built-in mounts)
- ISO standard: 6432 (Mini cylinder compliance)
Corrosion-resistant stainless steel cylinder with precision-ground rod (Ra≤0.4μm surface roughness). Features dual cushion adjustment screws for smooth end-stroke deceleration. Hermetically sealed with medical-grade lubrication compatible with 0.1μm filtered air. Optional FKM seals support steam cleaning environments.
- Food processing machinery (NSF compliant)
- Cleanroom automation in semiconductor production
- Chemical dosing systems with acid vapor exposure
- High-cycle micro positioning (up to 1,200 cpm)
- Marine equipment controls
Installation tip:
Apply anti-seize compound (nickel-based) on rod threads when used in saltwater environments.
Maximum side load: ≤3N. Lubrication interval: 500km stroke distance or 6 months.
| Property | Property Value |
|---|---|
| sku | MI10X10SUH |
| Rear Cover Type | Radial Air Inlet |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | <10mm> |
| Stroke | <10mm> |
