Airtac MI8~12 Stainless Steel Mini Cylinder MI10X10UTC
2. Integrated cushion rings on front/rear caps to mitigate impact during directional changes;
3. Multiple rear cap configurations for enhanced mounting flexibility;
4. Crimped and rolled structure securely connects stainless steel cylinder body with end caps;
5. Stainless steel construction (piston rod & cylinder) ensures corrosion resistance in moderately corrosive environments;
6. Comprehensive model variants and mounting accessories available upon request.
Category: Stainless Steel Mini Cylinders | Brand: AIRTAC | Series: MI8~12
AirTAC MI10X10UTC Stainless Steel Mini Cylinder Technical Details
- Series: MI8~12 Compact Cylinder Family
- Model: MI10X10UTC
- Bore size: 10mm (0.39")
- Stroke: 10mm (0.39") ±0.5mm tolerance
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Temperature range: -20℃ to 150℃
- Port size: M5×0.8 (dual ports standard)
- Cushioning: Adjustable rubber bumper (both ends)
- Material: SUS304 stainless steel body, CRMA piston rod
- Mounting: Foot/base mount (standard), optional flange/bracket kits
- Weight: 0.12kg (0.26lbs) ±3%
- Dimensions:
- Total length: 100mm (3.94")
- Body diameter: 20mm (0.79")
- Mounting hole spacing: 25mm × 12mm (0.98" × 0.47")
- Accessories: Optional magnetic switch (D-A93 series compatible)
Ultra-compact stainless steel pneumatic cylinder featuring corrosion-resistant construction for harsh environments. The MI10X10UTC combines 0.5μm surface finish precision with dual anti-rotation guides, delivering ±0.1mm repeat positioning accuracy. Requires 5μm filtered air with ISO VG32 hydraulic oil mist lubrication (0.1cc/min recommended).
- Cleanroom semiconductor handling robots
- Pharmaceutical tablet pressing mechanisms
- Food processing conveyor gate actuators
- Laboratory liquid dispensing systems
- UV sterilization chamber door controls
Maintenance tip:
Lubricate every 50km of cumulative stroke movement using NSF-H1 grade grease.
Avoid side loads exceeding 2N·m to prevent rod deflection.
| Property | Property Value |
|---|---|
| sku | MI10X10UTC |
| Rear Cover Type | Radial Air Inlet |
| Mounting Type | Center Pivot Bracket |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Bore Diameter | <10mm> |
| Stroke | <10mm> |
