Airtac MICD Air Cushion Double Rod Mini Cylinder MICD16X20
2. Integrated fixed cushion rings on front/rear end caps reduce impact shock during directional changes;
3. Multiple rear cap configurations simplify installation flexibility;
4. Riveted hybrid enclosure structure securely joins end caps to stainless steel cylinder barrel;
5. Stainless steel piston rod and barrel construction ensures reliable operation in mildly corrosive environments;
6. Comprehensive cylinder specifications and mounting accessories available for customized solutions.
Category: Double Rod Cylinders , Brand: AirTAC , Series: MICD
AirTAC MICD Series Pneumatic Cylinder MICD16X20 Technical Details
- Model: MICD16X20
- Type: Double-acting, dual rod, compact cylinder with air cushioning
- Bore size: 16mm (±0.1mm tolerance)
- Stroke: 20mm (adjustable ±1mm)
- Operating pressure: 0.05–0.9 MPa (7–130 PSI)
- Cushioning: Adjustable pneumatic buffer (both ends)
- Port size: M5x0.8 (dual ports on both ends)
- Piston speed: 50–800 mm/s (lubricated condition)
- Ambient temperature: -20℃ to 80℃
- Material: Barrel – Aluminum alloy (hard anodized), Rod – SUS304 stainless steel
- Seals: NBR (Nitrile) standard, optional Fluorocarbon (FKM)
- Weight: 0.28 kg (without accessories)
- Dimensions:
- Total length: 98mm (at mid-stroke)
- Body diameter: 22mm (±0.5mm)
- Rod diameter: 4mm (dual rods)
- Mounting bracket hole spacing: 32mm (ISO6432 standard)
- ISO certification: Compliant with ISO6432, VDMA 24562
Ultra-compact dual-rod cylinder featuring precision-machined guide rods for exceptional lateral load resistance. The integrated air cushioning system reduces end-impact noise to ≤70dB while maintaining 500km+ service life at full stroke cycles. Hermetically sealed magnetic ring option available for position sensing (M9/M12 connectors).
- PCB handling robots – precision component placement
- Pharmaceutical blister packaging machines – dual-action sealing
- Semiconductor wafer clamping – vibration-free operation
- Automated test equipment – repeatable linear motion
- Food processing lines – corrosion-resistant variant available
Installation protocol:
For optimal performance, maintain 0.5–1mm alignment tolerance during mounting.
Use ISO VG32 hydraulic oil mist lubrication (0.1–0.3cc/min flow rate).
Buffer adjustment requires 1.5mm hex key – turn clockwise to increase damping force.
| Property | Property Value |
|---|---|
| sku | MICD16X20 |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 16mm |
| Stroke | <20mm> |
