Airtac MICD Air Cushion Double Rod Mini Cylinder MICD16X225
2. Integrated fixed cushion rings on front/rear end caps reduce impact shock during directional changes;
3. Multiple rear cap configurations simplify installation flexibility;
4. Riveted hybrid enclosure structure securely joins end caps to stainless steel cylinder barrel;
5. Stainless steel piston rod and barrel construction ensures reliable operation in mildly corrosive environments;
6. Comprehensive cylinder specifications and mounting accessories available for customized solutions.
Category: Double Rod Cylinders , Brand: AirTAC , Series: MICD
AirTAC MICD Series Compact Double-Rod Cylinder MICD16X225 Specifications
- Model: MICD16X225
- Type: Double-acting, dual-rod mini cylinder with air cushion
- Bore size: 16mm
- Stroke: 225mm (±1.5mm tolerance)
- Operating pressure: 0.05–0.9 MPa
- Cushioning: Adjustable pneumatic cushion at both ends
- Temperature range: -20℃ to 80℃
- Port size: M5×0.8 (standard) with NPT1/8 optional
- Mounting style: Square body with 4xM3 threaded holes (32mm×32mm pattern)
- Rod material: Hard chrome-plated steel (C1035)
- Tube material: Anodized aluminum alloy
- Seal material: Heat-resistant NBR (Nitrile rubber)
- Protection rating: IP54 (standard), IP67 optional with wiper upgrade
- Weight: 580g ±3% (without accessories)
- Dimensions:
- Length: 295mm (stroke length + 70mm base)
- Width: 32mm (body square dimension)
- Height: 32mm (body square dimension)
A space-saving dual-rod actuator featuring synchronized bi-directional force output (46N at 0.6MPa) and precision end-position damping. The through-rod design eliminates rotational movement, making it ideal for alignment-critical applications. Includes built-in magnet for sensor mounting (ISO 21287 compliant).
- Precision wafer handling in semiconductor FOUP openers
- Simultaneous clamping in CNC fixture systems
- Linear guide alignment in 3D printer extruder assemblies
- Packaging machine product ejectors requiring dual-side force balance
- Optical lens coating equipment positioning stages
Installation note:
Maintain 0.5-1mm clearance between rods and load connections to prevent side load.
Lubricate with ISO VG32 turbine oil (1-2 drops per port monthly). Cushion adjustment
requires 2mm hex key – turn clockwise to increase damping force.
| Property | Property Value |
|---|---|
| sku | MICD16X225 |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 16mm |
| Stroke | 225mm |
