Airtac MICD Air Cushion Double Rod Mini Cylinder MICD16X25S
2. Integrated fixed cushion rings on front/rear end caps reduce impact shock during directional changes;
3. Multiple rear cap configurations simplify installation flexibility;
4. Riveted hybrid enclosure structure securely joins end caps to stainless steel cylinder barrel;
5. Stainless steel piston rod and barrel construction ensures reliable operation in mildly corrosive environments;
6. Comprehensive cylinder specifications and mounting accessories available for customized solutions.
Category: Double Rod Cylinders , Brand: AirTAC , Series: MICD
AirTAC MICD Series Dual Rod Mini Cylinder MICD16X25S Specifications
- Model: MICD16X25S
- Type: Double-acting with adjustable air cushion (both ends)
- Bore size: 16mm
- Stroke: 25mm
- Rod diameter: 6mm (dual rod)
- Operating pressure: 0.15–0.8 MPa
- Cushion stroke: 6mm (front/rear)
- Port size: M5x0.8 (standard) / NPT1/8 optional
- Weight: 0.26kg
- Dimensions: 100mm(L) × 32mm(W) × 40mm(H) (foot-mounted)
- Piston speed: 50–700mm/s
- Ambient temperature: -20℃ to 80℃
- Seal material: NBR (nitrile rubber)
- Mounting type: Standard foot mount (MF1)
- Rod thread: M6x1.0 (both ends)
- Protection rating: IP54
Ultra-compact dual-rod cylinder featuring symmetrical force output and position detection readiness. The integrated air cushion mechanism minimizes end-impact noise (≤70dB) while maintaining 95% energy absorption efficiency. Anodized aluminum construction with chrome-plated piston rod resists corrosion in humid environments.
- Precision alignment in semiconductor wafer handling
- Bi-directional clamping in CNC tool changers
- Z-axis positioning in 3D printing/pick-and-place systems
- Simultaneous actuation in packaging machine sealing bars
- Medical device linear motion control
Installation guidelines:
Maintain 0.5–1mm alignment tolerance during mounting. Lubricate with ISO VG32 turbine oil
before initial use. For vertical mounting, install rod-down orientation to prevent seal wear.
- Magnetic sensor kit: D-M9NW (cylinder groove compatible)
- Rod lock: MICD-LK series for mid-stroke holding
- Heat-resistant variant: Available with FKM seals (up to 120℃)
| Property | Property Value |
|---|---|
| sku | MICD16X25S |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 16mm |
| Stroke | <25 mm> |
