Airtac MICD Air Cushion Double Rod Mini Cylinder MICD16X30
2. Integrated fixed cushion rings on front/rear end caps reduce impact shock during directional changes;
3. Multiple rear cap configurations simplify installation flexibility;
4. Riveted hybrid enclosure structure securely joins end caps to stainless steel cylinder barrel;
5. Stainless steel piston rod and barrel construction ensures reliable operation in mildly corrosive environments;
6. Comprehensive cylinder specifications and mounting accessories available for customized solutions.
Category: Double Rod Cylinders , Brand: AirTAC , Series: MICD
AirTAC MICD Series Dual Rod Mini Cylinder with Air Cushion - MICD16X30
- Bore size: 16mm (Standard MICD Series)
- Stroke: 30mm (Customizable from 10-100mm)
- Operating pressure: 0.15–0.8 MPa
- Cushion type: Adjustable air cushion at both ends
- Temperature range: -20℃ to 80℃
- Port size: M5x0.8 (Standard) / NPT1/8 (Optional)
- Piston rod thread: M5x0.8 (Dual rod configuration)
- Mounting types: Front/rear threaded, foot-mounted
- Cylinder tube material: Aluminum alloy with hard anodization
- Rod material: Stainless steel (SUS304)
- Seal material: NBR (Nitrile rubber)
- Weight: 0.25kg (Body only) / 0.32kg (With accessories)
- Dimensions: 78mm(L) × 32mm(W) × 32mm(H)
- Max theoretical force: 51.5N @0.5MPa
- Max speed: 500mm/s
- Protection rating: IP54 (Standard) / IP67 (Optional)
Ultra-compact dual-rod pneumatic cylinder featuring synchronized movement and precise positioning through twin rod configuration. The integrated air cushion mechanism minimizes end-impact vibration (≤0.5mm residual stroke adjustment). Precision honed inner bore (Ra≤0.2μm) ensures ≤0.1mm repeat positioning accuracy. Corrosion-resistant construction with 25μm-thick anodized coating withstands humid environments.
- Precision alignment in SMT component placement machines
- Dual-axis synchronization in semiconductor wafer handling
- Compact clamping mechanisms for CNC tool changers
- Medical device actuation systems requiring bidirectional force
- Packaging line product flipping mechanisms
Installation guidelines:
Maintain ≤0.05mm perpendicularity tolerance during mounting.
Use rod-end bearings for angular misalignment compensation.
Lubricate with ISO VG32 hydraulic oil if operated below -10℃.
Recommended 5μm filtration for cushion adjustment valves.
| Property | Property Value |
|---|---|
| sku | MICD16X30 |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 16mm |
| Stroke | 30mm |
