Airtac MICD Air Cushion Double Rod Mini Cylinder MICD16X300
2. Integrated fixed cushion rings on front/rear end caps reduce impact shock during directional changes;
3. Multiple rear cap configurations simplify installation flexibility;
4. Riveted hybrid enclosure structure securely joins end caps to stainless steel cylinder barrel;
5. Stainless steel piston rod and barrel construction ensures reliable operation in mildly corrosive environments;
6. Comprehensive cylinder specifications and mounting accessories available for customized solutions.
Category: Double Rod Cylinders , Brand: AirTAC , Series: MICD
AirTAC MICD Series Dual Rod Mini Cylinder with Air Cushion MICD16X300
- Model: MICD16X300
- Series: MICD (Dual Rod Mini Cylinder with Air Cushion)
- Bore Size: 16 mm
- Stroke: 300 mm (Customizable 1-500mm)
- Operating Pressure: 0.15 - 0.8 MPa (21.7-116 PSI)
- Cushioning Type: Adjustable Air Cushion (Both Ends)
- Piston Speed: 50-800 mm/s (Lubricated)
- Operating Temperature: -20°C to 80°C (-4°F to 176°F)
- Port Size: M5x0.8 (Standard), Optional NPT1/8
- Mounting Type: Basic (Optional Accessories: MA-16 Foot Mount, MF-16 Front Flange)
- Rod Material: Stainless Steel (SUS304) with Hard Chrome Plating
- Cylinder Tube: Aluminum Alloy (6063-T5 Hard Anodized)
- End Covers: High-Strength PPS Resin
- Seal Material: NBR (Nitrile Rubber) Standard, Optional FKM/Viton
- Weight: 0.85 kg (1.87 lbs) ±3%
- Dimensions (L×W×H): 400 mm × 34 mm × 34 mm (15.75"×1.34"×1.34")
- Rod Diameter: 6 mm
- Maximum Side Load: 5.2N at midpoint
- Durability: 5,000 km (3,107 miles) stroke life with proper lubrication
This space-saving dual-rod cylinder features synchronized movement with air cushion adjustment screws at both ends for precise deceleration control. The symmetrical design ensures balanced force distribution, making it ideal for applications requiring alignment accuracy. The corrosion-resistant construction includes IP54-equivalent protection and supports both lubricated and non-lubricated air systems (requires initial lubrication if non-lubricated).
- Precision alignment in PCB conveyor systems
- Dual-arm gripping mechanisms in pharmaceutical packaging
- Z-axis positioning in 3D printing/pick-and-place machines
- Valve actuation in cleanroom environments
- Optical lens positioning systems
Installation Best Practices:
Use flexible couplings when connecting to driven loads. For vertical mounting,
add a guide mechanism to prevent piston rotation. Adjust cushion screws in
1/4-turn increments while monitoring with a pressure gauge (recommended 0.2-0.3MPa
for optimal cushioning).
| Property | Property Value |
|---|---|
| sku | MICD16X300 |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 16mm |
| Stroke | 300mm |
