Airtac MICD Air Cushion Double Rod Mini Cylinder MICD16X30S
2. Integrated fixed cushion rings on front/rear end caps reduce impact shock during directional changes;
3. Multiple rear cap configurations simplify installation flexibility;
4. Riveted hybrid enclosure structure securely joins end caps to stainless steel cylinder barrel;
5. Stainless steel piston rod and barrel construction ensures reliable operation in mildly corrosive environments;
6. Comprehensive cylinder specifications and mounting accessories available for customized solutions.
Category: Double Rod Cylinders , Brand: AirTAC , Series: MICD
AirTAC MICD16X30S Air Cushioned Double-Rod Miniature Cylinder Specifications
- Model: MICD16X30S
- Bore Size: 16mm (ISO 6432 standard)
- Stroke: 30mm (±1mm tolerance)
- Operating Pressure: 0.15-0.8 MPa
- Cushion Type: Adjustable air cushion (both ends)
- Action Type: Double-acting
- Port Size: M5x0.8 (1/8" NPT optional)
- Rod Thread: M5x0.8 external thread (both ends)
- Seal Material: Nitrile Butadiene Rubber (NBR)
- Temperature Range: -20℃ to +80℃
- Piston Speed: 50-700 mm/s (optimal at 200-500 mm/s)
- Mounting Types: Foot, front flange, rear flange, or side mounts
- Protection Rating: IP40 (IP67 with optional wiper seal)
- Weight: 0.25 kg (excluding accessories)
- Dimensions (L×W×H): 78mm × 32mm × 32mm (extended length: 108mm)
- Rod Diameter: 6mm (chrome-plated steel)
- Tube Material: Anodized aluminum alloy
- End Cap Material: Die-cast aluminum
- Port Position: Front ends (axial ports)
A precision-engineered compact cylinder featuring dual air cushioning for smooth end-of-stroke deceleration. The symmetrical double-rod design enables balanced force distribution and allows for position sensing at both ends. Optimized for high-cycle applications with its hardened piston rods and wear-resistant seals. Requires ISO 8573-1:2010 Class 3 lubricated or non-lubricated air.
- PCB handling robots in electronics manufacturing
- Precision clamping mechanisms in CNC tool changers
- Valve actuation in medical analyzer instruments
- Conveyor gate control in pharmaceutical packaging
- Optical lens positioning systems
Installation recommendation:
Maintain 0.5-1mm alignment tolerance during mounting. For vertical installations,
use the optional locknut (ASNU6) to prevent rod rotation. Adjust cushion needles
clockwise to increase damping force. Maximum side load: 3N at full extension.
| Property | Property Value |
|---|---|
| sku | MICD16X30S |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 16mm |
| Stroke | 30mm |
