Airtac MICJ Adjustable Mini Cylinder MICJ16X100-75S
The AirTAC MICJ Adjustable Mini Cylinder MICJ16X100-75S is a genuine double acting, double rod, adjustable stroke + cushion round-body mini air cylinder with a Ø16mm bore and 100mm stroke, M5×0.8 air ports and a stainless-steel barrel and rod for mildly corrosive environments. Its ISO 6432 mounting interface fits standard ISO 6432 mini-cylinder mounting interfaces.
- BoreØ16 mm
- Stroke100 mm
- Port sizeM5×0.8
- Acting typeDouble acting, double rod, adjustable stroke + cushion
- Rod threadM6×1.0
- CushionVariable air cushion, both ends
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac MICJ Adjustable Mini Cylinder MICJ16X100-75S
Trim the forward stop by up to 75 mm on site without swapping cylinders: the MICJ16X100-75S is a double-acting, round-body stainless-steel mini cylinder with an adjustable extend stroke and an adjustable air cushion at both ends. The external screw sets the extend end position from 25 to 100 mm, while the needle cushions soak up high-speed shock. A built-in magnet (-S) enables CMSG, DMSG, or EMSG position sensing.
The stainless barrel and rod resist mild corrosion and washdown, and the body conforms to the ISO 6432 mounting interface for standard mini brackets.
Airtac MICJ Adjustable Mini Cylinder MICJ16X100-75S Technical Specifications
| Model | Airtac MICJ Adjustable Mini Cylinder MICJ16X100-75S |
|---|---|
| Series | MICJ ISO 6432 mini cylinder |
| Bore size | Ø16 mm |
| Stroke | 100 mm |
| Acting type | Double acting, double rod, adjustable stroke + cushion |
| Port size | M5×0.8 |
| Rod thread | M6×1.0 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Variable air cushion, both ends |
| Max standard stroke | Up to 500 mm |
Specifications follow the official AirTAC MI/MIC (ISO 6432) datasheet. Barrel & rod: stainless steel (round-body, riveted construction). Thread options: PT (blank) / G.
Theoretical Output Force (Ø16mm)
| Pressure | Force (both ways) |
|---|---|
| 0.5 MPa | 86 N |
| 0.7 MPa | 121 N |
| Max (@1.0 MPa) | 18 kgf |
MIJ / MICJ are double-rod: the rear rod that carries the stroke adjuster exits the rear cover, so both piston faces lose rod area. The rod-side (annular) area is used for both directions (conservative).
Model Code: Airtac MICJ Adjustable Mini Cylinder MICJ16X100-75S
| MICJ | ISO 6432 round-body mini cylinder (adjustable-stroke, variable cushion). |
|---|---|
| 16 | Bore size in mm. |
| ×100 | Stroke length in mm. |
| -75 | Adjustable stroke window (mm the extend stroke can be shortened on site). |
| -S | Optional built-in magnet for CMSG / DMSG / EMSG sensors. |
MI-family variants: MI / MIC (double acting ±cushion), MSI / MTI (single acting push / pull), MID / MICD (double rod ±cushion), MIJ / MICJ (double rod, adjustable stroke ±cushion). Back covers CA / U / R / CM. Mounting LB / FA / SDB / TC.
Where the Airtac MICJ Adjustable Mini Cylinder MICJ16X100-75S Is Used
Gauge Positioning
Dial in the exact 25 to 100 mm extend stop to push a measuring gauge against soft parts without crushing them, relying on the dual air cushions to absorb the impact at high speed.
Sample Diverting
Use the built-in magnet with a DMSG switch to confirm the extend position when routing small lab vials, tuning the needle cushion to prevent liquid splashing on the end stroke.
Is the Airtac MICJ Adjustable Mini Cylinder MICJ16X100-75S the Right Cylinder?
For lighter duty, the MIJ bumper-only series is the next step down, as there is no smaller cushioned MICJ bore. This 16 mm model is ideal when you need to dial in a precise extend position and control impact at high speeds up to 800 mm/s.
The stop screw sets the end position but is not a mid-stroke lock; the piston will drift on air loss, so use an external rod lock or pilot check valve to hold a suspended load. Mount via LB foot, FA flange, or TC trunnion (SDB is not available on this adjustable variant). The -S magnet allows for direct sensor switches.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT / G)
- ✓ Magnet (-S) for sensors?
- ✓ Back cover (CA/U/R/CM) & mount (LB/FA/SDB/TC)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Do not dismantle the riveted front/back covers.
- check Use correct back cover (CA/U/R/CM) & mount (LB/FA/SDB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac MICJ Adjustable Mini Cylinder MICJ16X100-75S FAQ
At 0.7 MPa, push is 140.7 N and pull is 120.9 N. The theoretical maximum force is 20.5 kgf at 1.0 MPa.
An external screw shortens the extend stroke by up to 75 mm on site, and an adjustable needle air cushion at both ends decelerates the piston near the end of travel. The cushion only slows the piston; it does not lock or hold the load. If air pressure is lost, the cylinder will drift, requiring an external rod lock for suspended loads.
