Airtac MKJ Adjustable Cylinder MKJ10X15-20S
The AirTAC Airtac MKJ Adjustable Cylinder MKJ10X15-20S is a genuine MK multi-mount cylinder (adjustable stroke), 10 mm bore. Its compact square body fixes from six directions and mounts side by side to save space. It delivers about 39.3 N of push force at 0.5 MPa. A bumper cushions the impact. As an MK unit a fixed rod stops the piston rod rotating.
- TypeMulti-mount, adjustable stroke
- SeriesMK (no-rotating)
- Bore10 mm
- Push thrust @0.5 MPa39.3 N
- Operating pressure0.2 - 1.0 MPa (28 - 145 psi)
- Port sizeM5x0.8
- CushionBumper
- MagnetWith magnet (sensor-ready)
- ThreadPT
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac MKJ Adjustable Cylinder MKJ10X15-20S
The MKJ10X15-20S is an AirTAC MKJ no-rotating multi-mount cylinder with a compact square body that fixes from 6 directions: front, back, left, right, top and bottom. Bodies mount side by side to save space, with magnetic-switch slots around the body and high guide precision without added lubrication. This double-acting model has a 10 mm bore and 15 mm stroke, plus a 20 mm adjustable-stroke range from the J suffix. At 0.5 MPa it delivers a theoretical push thrust of 39.3 N for light clamping, positioning and stopping work, with a bumper as the cushion.
This is a genuine AirTAC part. The MK family prevents rod rotation via a no-rotating plate, brass bushing and fixed rod, unlike the standard MD family. The trailing S means this SKU is supplied WITH a magnet, so magnetic switches can be sensed in the body slots. Operating pressure is 0.2-1.0 MPa (28-145 psi), the medium is air filtered to 40 um, proof pressure is 1.5 MPa (215 psi), temperature is -20 to 70 C (0 to 150 C only with the optional high-temperature seal material), and the thread is PT. We confirm dimensions and sizing from the datasheet on request.
Airtac MKJ Adjustable Cylinder MKJ10X15-20S Technical Specifications
| Model | Airtac MKJ Adjustable Cylinder MKJ10X15-20S |
|---|---|
| Type | Multi-mount cylinder, adjustable stroke |
| Series | MK (no-rotating) |
| Bore | 10 mm |
| Push thrust @0.5 MPa | 39.3 N |
| Port size | M5x0.8 (PT thread) |
| Magnet | With magnet (S) |
| Fluid | Air, filtered to 40 um |
|---|---|
| Operating pressure | 0.2 - 1.0 MPa (28 - 145 psi) |
| Proof pressure | 1.5 MPa (215 psi) |
| Temperature | -20 to 70 C |
| Speed range | 30 - 500 mm/s |
| Cushion | Bumper |
| Mounting | Fix from 6 directions; mountable side by side |
Specifications follow the official AirTAC MD/MK multi-mount data. The front cover and piston are short, so avoid an over-long stroke. An optional high-temperature seal material extends the range to 0 to 150 C. Overall dimensions vary per stroke and allowable side-load is published as curves — ask us and we confirm from the datasheet.
How to choose
Select the 10 mm bore when roughly 39.3 N of theoretical push thrust at 0.5 MPa fits the job; other bores give more or less thrust. Choose MK over MD when rotation must be prevented, and the J version when you need a 10, 20 or 30 mm adjustable range added to the 15 mm stroke (here 20 mm). This is double acting. The S suffix means this SKU includes the magnet for switch sensing; omit S if you do not need it. Thread is PT, with G available. Respect the short body cover and avoid over-long strokes, and route side-load questions to us.
Applications
Sensor-monitored stopper
Stops cartons or parts on a line with a non-rotating plate, while the built-in magnet lets switches in the body slots confirm extend and retract.
Pick-and-place head
Carries small parts between stations in a compact pick-and-place module, with side-by-side mounting and a rod that holds its angular position.
Small-parts clamp
Clamps light components in a tight fixture, fixed from any of 6 body faces and end-stroke position tuned with the adjustable range.
FAQ
What does the S in MKJ10X15-20S mean?
The trailing S means this SKU is supplied WITH a magnet in the piston, so magnetic switches can be sensed in the slots around the body. The same model without the S has no magnet. Magnet is an option on MD/MK cylinders, not a fixed feature, so order the S version only when you need switching.
Why must the stroke stay within the bore's table?
The multi-mount body has a short cover, so over-long strokes reduce guidance quality and reliability. Keep the stroke within the listed range for the bore and use the MKJ adjustable range to fine-tune the end position. Confirm exact dimensions and side-load limits from the datasheet, which we can supply on request.
