Airtac MKJ Adjustable Cylinder MKJ10X25-10
2. Multiple mounting configurations for simplified installation;
3. Supports parallel cylinder mounting to optimize space utilization;
4. Precision-guided piston rod eliminates need for external lubrication;
5. Integrated piston rod locking block prevents rotation during operation;
6. Extensive range of models and specifications for diverse applications;
7. Optional high-temperature seals available for 0-150℃ operating range (Optional).
Category: Adjustable Cylinders | Brand: AirTAC | Series: MKJ Series
AirTAC MKJ Adjustable Cylinder MKJ10X25-10 Technical Details
- Full model code: MKJ10X25-10
- Bore size: 10mm (standard ISO cylinder sizing)
- Stroke: 25mm ±1mm adjustable (mechanical stopper system)
- Operating pressure: 0.05–0.9 MPa
- Piston speed: 50–800 mm/s (lubricated condition)
- Buffer type: Adjustable cushioning (dual-end shock absorption)
- Port thread: M5×0.8 (standard) / G1/8 optional
- Ambient temperature: -10℃ to 70℃ (dry air required below 0℃)
- Piston material: Aluminum alloy (anodized surface)
- Rod material: Stainless steel SUS304
- Seal type: NBR rubber seals (oil-resistant)
- Weight: 0.32kg (bare cylinder without accessories)
- Dimensions:
- Length: 104mm (fully retracted)
- Width: 32mm (body diameter)
- Height: 32mm (mounting bracket included)
Compact profile cylinder with precision stroke adjustment capability, featuring a unique mechanical stopper mechanism that allows ±1mm fine-tuning. The double-acting design incorporates wear-resistant guide bushings and integrated shock absorbers for high-cycle applications. Compatible with auto-switch sensors (slot width 6.5mm).
- Precision part insertion in PCB assembly lines
- Label positioning mechanisms in packaging machinery
- Clamping force adjustment in CNC jig systems
- Medical device actuator assemblies
- Semiconductor wafer handling equipment
Installation guidance:
For optimal performance, align cylinder axis with motion direction (±2° tolerance).
Use locking nuts (M5) on adjustment screws after calibration. Lubricate through air
port with ISO VG32 turbine oil for initial 500km stroke maintenance.
| Property | Property Value |
|---|---|
| sku | MKJ10X25-10 |
| Adjustable Stroke | <10mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | <10mm> |
| Stroke | <25 mm> |
