Airtac MKJ Adjustable Cylinder MKJ10X30-30S
2. Multiple mounting configurations for simplified installation;
3. Supports parallel cylinder mounting to optimize space utilization;
4. Precision-guided piston rod eliminates need for external lubrication;
5. Integrated piston rod locking block prevents rotation during operation;
6. Extensive range of models and specifications for diverse applications;
7. Optional high-temperature seals available for 0-150℃ operating range (Optional).
Category: Adjustable Cylinders | Brand: AirTAC | Series: MKJ Series
AirTAC MKJ Adjustable Cylinder MKJ10X30-30S Technical Details
- Model Code: MKJ10X30-30S
- Type: Double-acting adjustable stroke cylinder
- Bore size: 10mm (precision honed tube)
- Stroke: 30mm (adjustable through stopper mechanism)
- Adjustment range: 0-30mm continuous position locking
- Operating pressure: 0.05-0.9 MPa
- Port size: M5x0.8 (dual ports for forward/return)
- Piston rod material: Hard chrome-plated steel (4mm diameter)
- Tube material: Aluminum alloy oxidation-resistant barrel
- Temperature range: -10℃ to 80℃
- Cushioning: Rubber bumper + adjustable air cushion
- Mounting style: Standard female thread (M5x0.8 mounting holes)
- Weight: 210g ±5g (without accessories)
- Dimensions: 108mm(L) × 28mm(W) × 28mm(H) (retracted position)
- Extended length: 138mm (full stroke)
- Repeat accuracy: ±0.2mm
- IP rating: IP54 (standard seals)
Precision micro cylinder with mechanical stroke adjustment lock, featuring dual anti-rotation guide rods for enhanced positional stability. The gold-anodized barrel provides corrosion resistance in humid environments. Includes built-in magnet for position sensing compatibility. Requires 5μm filtered lubricated air (ISO 8573-1 class 3).
- PCB board component insertion machines
- Medical device assembly positioning stages
- Semiconductor wafer handling actuators
- Textile machinery thread tension adjusters
- Automated test equipment probe positioning
Installation recommendation:
Mount using precision alignment jigs to prevent side load. Lubricate with ISO VG32 hydraulic oil
during initial setup. For vertical installations, add 10% extra stroke margin for cushioning effectiveness.
Maintenance note:
Replace wear bands after 5 million cycles in high-speed applications (>500mm/s).
Avoid using silicone-based lubricants with NBR seals.
| Property | Property Value |
|---|---|
| sku | MKJ10X30-30S |
| Adjustable Stroke | 30mm |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | <10mm> |
| Stroke | 30mm |
