Airtac MKJ Adjustable Cylinder MKJ10X35-20S
2. Multiple mounting configurations for simplified installation;
3. Supports parallel cylinder mounting to optimize space utilization;
4. Precision-guided piston rod eliminates need for external lubrication;
5. Integrated piston rod locking block prevents rotation during operation;
6. Extensive range of models and specifications for diverse applications;
7. Optional high-temperature seals available for 0-150℃ operating range (Optional).
Category: Adjustable Cylinders | Brand: AirTAC | Series: MKJ Series
AirTAC MKJ Adjustable Cylinder MKJ10X35-20S Specifications
- Model: MKJ10X35-20S
- Type: Double-acting adjustable stroke cylinder
- Bore size: 10mm
- Stroke: 35mm (adjustable)
- Operating pressure: 0.15–0.8 MPa
- Operating temperature: -20℃ to 80℃
- Cushion type: Adjustable pneumatic cushion
- Mounting style: Standard foot mounting (MF1)
- Port size: 1/8" NPT (M5 optional)
- Material: Aluminum alloy body, stainless steel piston rod
- Rod thread: M5×0.8 external thread
- Stroke adjustment: ±2mm via rotating end cover
- Repeat positioning accuracy: ±0.2mm
- Max speed: 500mm/s
- Lubrication: Non-lube (pre-lubricated)
- Protection rating: IP40
- Weight: 0.25kg
- Dimensions: 130mm(L) × 42mm(W) × 42mm(H)
Precision micro-adjustment cylinder with mechanical stop mechanism, featuring dual anti-rotation design for stable positioning. The anodized surface treatment enhances corrosion resistance in humid environments. Integrated cushioning adjustment prevents impact damage during high-speed operation.
- Semiconductor wafer handling robots
- Precision press-fit operations in electronics assembly
- Pharmaceutical filling/packaging equipment
- Automotive component testing fixtures
- Optical lens positioning systems
Installation note:
Ensure alignment tolerance ≤0.05mm during mounting. For stroke adjustment,
loosen lock nut and rotate end cap clockwise to decrease stroke (1 full rotation ≈ 0.5mm adjustment).
Apply thread sealant to rod end when attaching accessories.
- Re-lubricate every 500km stroke travel with ISO VG32 turbine oil
- Inspect cushion seal every 6 months in continuous operation
- Max side load: 2.5N at full extension
| Property | Property Value |
|---|---|
| sku | MKJ10X35-20S |
| Adjustable Stroke | <20mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | <10mm> |
| Stroke | 35mm |
