Airtac MKJ Adjustable Cylinder MKJ10X5-10
The AirTAC Airtac MKJ Adjustable Cylinder MKJ10X5-10 is a genuine MK multi-mount cylinder (adjustable stroke), 10 mm bore. Its compact square body fixes from six directions and mounts side by side to save space. It delivers about 39.3 N of push force at 0.5 MPa. A bumper cushions the impact. As an MK unit a fixed rod stops the piston rod rotating.
- TypeMulti-mount, adjustable stroke
- SeriesMK (no-rotating)
- Bore10 mm
- Push thrust @0.5 MPa39.3 N
- Operating pressure0.2 - 1.0 MPa (28 - 145 psi)
- Port sizeM5x0.8
- CushionBumper
- MagnetWithout magnet
- ThreadPT
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac MKJ Adjustable Cylinder MKJ10X5-10
The MKJ10X5-10 is a short-stroke, adjustable, no-rotating multi-mount cylinder in AirTAC's MK family. The compact square body fixes from six directions - front, back, left, right, top and bottom - so cylinders mount side by side to save space, with switch slots around the body and high guide precision with no added lubricant. The 10mm double-acting bore produces 39.3 N theoretical push (33.0 N pull) at 0.5 MPa, works on 0.2-1.0 MPa (28-145 psi) filtered air at 30-500 mm/s, and cushions through a bumper. The 5mm base stroke carries a 10mm adjustable range for fine setup.
This is a genuine AirTAC part. The MK family prevents rod rotation via a fixed rod, no-rotating plate and brass bushing (typical construction - bore detail in the datasheet), whereas the MD family is the standard type that allows rotation. This SKU has no trailing S, so it is supplied without a magnet; choose an -S code if you need one. Overall dimensions and sizing are confirmed from the datasheet on request.
Airtac MKJ Adjustable Cylinder MKJ10X5-10 Technical Specifications
| Model | Airtac MKJ Adjustable Cylinder MKJ10X5-10 |
|---|---|
| Type | Multi-mount cylinder, adjustable stroke |
| Series | MK (no-rotating) |
| Bore | 10 mm |
| Push thrust @0.5 MPa | 39.3 N |
| Port size | M5x0.8 (PT thread) |
| Magnet | Without magnet |
| Fluid | Air, filtered to 40 um |
|---|---|
| Operating pressure | 0.2 - 1.0 MPa (28 - 145 psi) |
| Proof pressure | 1.5 MPa (215 psi) |
| Temperature | -20 to 70 C |
| Speed range | 30 - 500 mm/s |
| Cushion | Bumper |
| Mounting | Fix from 6 directions; mountable side by side |
Specifications follow the official AirTAC MD/MK multi-mount data. The front cover and piston are short, so avoid an over-long stroke. An optional high-temperature seal material extends the range to 0 to 150 C. Overall dimensions vary per stroke and allowable side-load is published as curves — ask us and we confirm from the datasheet.
How to choose
The 10mm bore suits short moves needing up to 39.3 N push or 33.0 N pull at 0.5 MPa; step up a bore for more thrust. MKJ is the adjustable-stroke, no-rotating variant - double acting, with a 10, 20 or 30mm adjustable range over the base stroke. This model pairs a 5mm base stroke with a 10mm adjustment, ideal where travel must be trimmed in place; the short cover cautions against over-long strokes, and side-load limits come from the datasheet. No S in the code means no magnet is fitted, and the thread is PT as standard or G when ordered with G.
Applications
Small-parts clamping
Mounted on the side of a machining or assembly jig, the non-turning rod drives a clamp pad straight down onto a small part. The 5mm stroke with 10mm adjustment is tuned once to the part height and holds with 39.3 N at 0.5 MPa.
Jig positioning pin
In a drill or weld jig, the cylinder extends a locating pin that must enter the workpiece square - the no-rotating plate guarantees pin orientation, and 6-direction fixing lets it be bolted wherever the fixture layout allows.
Lift-and-locate riser
Fitted under a light carrier plate, the short-stroke unit raises a part a few millimetres to clear a locating edge. Bumper cushioning protects the small lift, and the bumper-stopped return keeps the cycle smooth.
FAQ
How do I read the stroke figures in MKJ10X5-10?
The 5 after the X is the base stroke in millimetres and the -10 is the adjustable range, so effective travel is set anywhere within 5mm plus 10mm of adjustment. There is no trailing S, so this cylinder is supplied without a magnet; add S to the code for the magnet version. Thread is PT by default, or G on request.
Can I use a long stroke on this compact body?
No - the short cover on this cylinder family cautions against over-long strokes. Double-acting bore-10 strokes run to 35mm, and this model is intended for short, adjustable moves. Overall dimensions and allowable side-load vary with bore and stroke, so confirm both from the datasheet before fixing the mounting.
