Airtac MKJ Adjustable Cylinder MKJ16X10-10
$41.17
Regular price
$48.67
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
MKJ16X10-10
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Compliant with enterprise standards;
2. Multiple mounting configurations for simplified installation;
3. Supports parallel cylinder mounting to optimize space utilization;
4. Precision-guided piston rod eliminates need for external lubrication;
5. Integrated piston rod locking block prevents rotation during operation;
6. Extensive range of models and specifications for diverse applications;
7. Optional high-temperature seals available for 0-150℃ operating range (Optional).
Category: Adjustable Cylinders | Brand: AirTAC | Series: MKJ Series
Installation guidelines:
Mount on flat surface with 0.02mm parallelism tolerance. Use anti-vibration
washers when operating above 500mm/s. Lubricate every 6 months under normal
duty cycles (2000 cycles/day).
2. Multiple mounting configurations for simplified installation;
3. Supports parallel cylinder mounting to optimize space utilization;
4. Precision-guided piston rod eliminates need for external lubrication;
5. Integrated piston rod locking block prevents rotation during operation;
6. Extensive range of models and specifications for diverse applications;
7. Optional high-temperature seals available for 0-150℃ operating range (Optional).
Category: Adjustable Cylinders | Brand: AirTAC | Series: MKJ Series
AirTAC MKJ16X10-10 Adjustable Cylinder Technical Specifications
- Model: MKJ16X10-10 (Standard type with adjustable stroke)
- Bore size: Ø16mm (ISO 6432 standard)
- Stroke: 10mm (Mechanically adjustable ±0.5mm)
- Mounting type: Foot-mounted (MF1 style) with dual mounting holes
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Cushioning: Adjustable pneumatic cushion at both ends
- Port size: M5x0.8 (Rc1/8 adaptor optional)
- Ambient temperature: -20℃ to 80℃ (NBR seals)/ -20℃ to 60℃ (Polyurethane seals)
- Piston speed: 50–700 mm/s (lubricated condition)
- Repeat positioning accuracy: ±0.2mm
- Weight: 0.32 kg (NBR seals version)
- Dimensions: 100mm(L) × 32mm(W) × 32mm(H) (Stroke extended state)
- Rod thread: M6×1.0 external thread (8mm length)
- Material: Aluminum alloy barrel, Chrome-plated piston rod
Precision mini cylinder featuring dual micro-adjustment screws (1mm pitch) for fine stroke calibration. The anodized barrel incorporates wear-resistant guides and IP54-rated dust protection. Requires ISO VG32 or equivalent hydraulic oil mist lubrication for optimal performance.
Industrial Applications:
- Semiconductor wafer handling robots
- Precision stamping die positioners
- Optical lens polishing equipment
- Pharmaceutical blister packaging machines
- PCB drilling press depth control
Installation guidelines:
Mount on flat surface with 0.02mm parallelism tolerance. Use anti-vibration
washers when operating above 500mm/s. Lubricate every 6 months under normal
duty cycles (2000 cycles/day).
| Property | Property Value |
|---|---|
| sku | MKJ16X10-10 |
| Adjustable Stroke | <10mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 16mm |
| Stroke | <10mm> |
