Airtac MPEF Embedded Mounting Threaded Cylinder MPEF12X10N
2、Supports modular integration of multiple cylinders, featuring versatile mounting options to optimize spatial efficiency in installation layouts;
3、No additional mounting accessories required;
4、Multiple bore sizes available to meet diverse application requirements.
Category: Needle Cylinders , Brand: Airtac , Series: MPEF
AirTAC MPEF12X10N Embedded Threaded Cylinder Specifications
- Model: MPEF12X10N
- Type: Embedded thread mounting cylinder (double-acting)
- Bore size: 12mm
- Stroke: 10mm (±1mm tolerance)
- Operating pressure: 0.1–0.8 MPa
- Operating temperature: -20℃ to 80℃
- Cushion type: Adjustable buffer at both ends
- Mounting style: M6×1.0 embedded thread
- Port size: M5×0.8 (standard) with Rc1/8 adapter optional
- Piston material: Aluminum alloy with hard anodization
- Rod material: SUS304 stainless steel
- Seal material: NBR (nitrile rubber)
- Weight: 0.25kg (excluding accessories)
- Dimensions:
- Body diameter: Φ12mm
- Total length (extended): 58mm ±0.5mm
- Mounting height: 20mm (from base to centerline)
- Rod thread: M4×0.7 external thread
Ultra-compact cylinder specifically engineered for space-constrained installations requiring flush mounting. Features corrosion-resistant construction with IP54 protection rating, making it suitable for cleanroom environments. The integrated thread design eliminates external mounting brackets, reducing overall system footprint by 30-40% compared to standard cylinders.
- Medical device positioning mechanisms
- Semiconductor wafer handling robots
- Precision dispensing equipment
- Compact automation in 3C industry (Computer, Communication, Consumer electronics)
- Miniature fixture clamping systems
Installation notes:
- Ensure 0.5mm minimum clearance around threaded body during embedding
- Use torque ≤1.2N·m during mounting to prevent thread deformation
- Apply silicone-free lubricant (ISO VG32 equivalent) for initial commissioning
- Recommended air filtration: 5μm with auto-drain
| Property | Property Value |
|---|---|
| sku | MPEF12X10N |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | Non-threaded |
| Cushion Type | Non-cushioned |
| Bore Diameter | 12mm |
| Stroke | <10mm> |
