Airtac MPEF Embedded Mounting Threaded Cylinder MPEF6X10
2、Supports modular integration of multiple cylinders, featuring versatile mounting options to optimize spatial efficiency in installation layouts;
3、No additional mounting accessories required;
4、Multiple bore sizes available to meet diverse application requirements.
Category: Needle Cylinders , Brand: Airtac , Series: MPEF
AirTAC MPEF6X10 Built-in Threaded Cylinder Specifications
- Model: MPEF6X10
- Type: Double-acting, built-in threaded cylinder
- Bore size: 6mm
- Stroke: 10mm
- Operating pressure: 0.15–0.8 MPa
- Thread type: M5×0.8 (internal thread)
- Cushioning: Rubber buffer (adjustable)
- Operating temperature: -20℃ to 80℃
- Piston speed: 50–800 mm/s
- Mounting hole depth: 15mm (minimum)
- Seal material: NBR (nitrile rubber)
- Weight: 0.048 kg
- Dimensions:
- Total length: 50mm (excluding rod)
- Body diameter: 16mm
- Rod diameter: 3mm
- Mounting flange: 20mm × 20mm
- Protection class: IP40
Ultra-compact threaded cylinder designed for embedded installations in confined spaces. Features precision-ground piston rod (chrome-plated) and anti-rotation design for stable linear motion. Includes dual air ports (G1/8) with optional 360° adjustable orientation. Requires lubrication with ISO VG32 hydraulic oil if not pre-lubricated.
- Micro-positioning in semiconductor handling robots
- Clamping mechanisms in CNC tool changers
- Valve actuation in compact fluid control systems
- Precision alignment stages for optical equipment
- Medical device actuation components
Installation guidelines:
Ensure 0.5mm minimum clearance around embedded section. Use torque ≤1.2N·m during thread installation.
Align ports within ±2° of target position. Pre-charge with 0.1MPa air during alignment for optimal seal seating.
| Property | Property Value |
|---|---|
| sku | MPEF6X10 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | External Thread |
| Cushion Type | Non-cushioned |
| Bore Diameter | <6mm> |
| Stroke | <10mm> |
