Airtac MPEF Embedded Mounting Threaded Cylinder MPEF8X15
2、Supports modular integration of multiple cylinders, featuring versatile mounting options to optimize spatial efficiency in installation layouts;
3、No additional mounting accessories required;
4、Multiple bore sizes available to meet diverse application requirements.
Category: Needle Cylinders , Brand: Airtac , Series: MPEF
AirTAC MPEF8X15 Embedded Threaded Cylinder Specifications
- Model: MPEF8X15
- Type: Compact embeddable cylinder with threaded body
- Bore size: 8mm (0.31")
- Stroke: 15mm (0.59")
- Operating pressure: 0.05–0.9 MPa (7–130 PSI)
- Ambient temperature: -20℃ to 80℃ (-4°F to 176°F)
- Port thread: M5×0.8 (standard) or Rc1/8 (optional)
- Cushioning: Adjustable rubber buffer
- Piston material: Aluminum alloy with hard anodizing
- Rod material: Stainless steel SUS304
- Seal type: NBR + PU combination seals
- Weight: 85g (0.19 lbs)
- Dimensions:
- Body length: 52mm (2.05")
- Mounting width: 20mm (0.79")
- Total height (with rod): 72mm (2.83")
Ultra-compact threaded cylinder designed for direct embedding in machinery structures. Features anti-rotation guide grooves and dual mounting orientations (horizontal/vertical). The nickel-plated end covers provide corrosion resistance in humid environments. Requires ISO 8573-1:2010 Class 3-4-3 compressed air.
- Precision clamping in CNC tool changers
- Micro-positioning in semiconductor handling robots
- Actuation of inspection probes in coordinate measuring machines
- Compact locking mechanisms in 3D printer assemblies
- Valve control in portable medical oxygen concentrators
Installation guidelines:
Maximum side load ≤1.5N. Use thread-locking compound on mounting screws (M4×0.7).
Maintain 0.5mm clearance around cylinder body when embedding. Lubricate with ISO VG32
turbine oil if used in continuous reciprocation applications.
| Property | Property Value |
|---|---|
| sku | MPEF8X15 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | External Thread |
| Cushion Type | Non-cushioned |
| Bore Diameter | <8mm> |
| Stroke | <15mm> |
