Airtac MPG Standard Panel Mount Cylinder MPG10X10
2. High-precision piston rod guidance eliminates the need for external lubrication;
3. Advanced rubber encapsulation process on rear cover ensures superior cushioning performance;
4. Multiple mounting configurations and optional accessories ensure flexible installation solutions tailored to client needs;
5. Optional magnetic version with integrated position sensing capability;
6. Pre-machined sensor slot on barrel enables convenient magnetic proximity sensor installation;
7. Comprehensive bore size selection accommodates diverse application requirements.
Category: Multi-position Cylinders | Brand: AIRTAC | Series: MPG
AirTAC MPG Standard Panel Cylinder MPG10X10 Technical Details
- Model Series: MPG (Panel Mount Series)
- Bore Size: 10mm (Precision honed cylinder tube)
- Stroke: 10mm (±0.5mm tolerance)
- Operating Pressure: 0.15-0.8 MPa
- Buffer Type: Rubber cushion (both ends)
- Mounting Style: Front panel flange mounting (4x M3 threaded holes)
- Port Thread: M5x0.8 (Dual ports for forward/return action)
- Piston Rod Material: SUS304 stainless steel (3mm diameter)
- Cylinder Tube: Hard anodized aluminum alloy
- Seal Material: NBR (Nitrile) with wear-resistant ring
- Operating Temperature: -20℃ to +80℃
- Weight: 120g ±5% (without accessories)
- Dimensions:
- Length: 40mm (cylinder body) + 10mm stroke
- Width: 22mm (flange mounting surface)
- Height: 22mm (including rod end)
- Protection Class: IP40 (standard sealing)
- Theoretical Force:
- Thrust @0.5MPa: 3.92N
- Tension @0.5MPa: 3.43N
Ultra-compact panel cylinder optimized for space-constrained automation systems. Features precision-ground rod guides for smooth linear motion and anti-rotation design for stable tooling alignment. Integrated mounting flange allows direct installation on equipment panels without additional brackets. Requires 5μm filtered compressed air with 1-2 drops of ISO VG32 lubricator oil per m³.
- PCB board clamping mechanisms
- Micro-dispenser actuation in medical devices
- Optical lens positioning systems
- Semiconductor wafer handling robots
- Desktop CNC tool changers
Installation Tip:
Use vibration-resistant thread locker on mounting screws. For vertical installations,
add a drip cup if using non-lubricated air. Maximum side load capacity: 0.3N·m.
| Property | Property Value |
|---|---|
| sku | MPG10X10 |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M3×0.5 |
| Piston Rod Thread Type | External Thread |
| Magnet | Non-magnetic |
| Bore Diameter | <10mm> |
| Stroke | <10mm> |
