Airtac MPG Standard Panel Mount Cylinder MPG10X20SN
$24.62
Regular price
$32.12
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
MPG10X20SN
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Compact structure, small footprint, and lightweight design enhance space efficiency;
2. High-precision piston rod guidance eliminates the need for external lubrication;
3. Advanced rubber encapsulation process on rear cover ensures superior cushioning performance;
4. Multiple mounting configurations and optional accessories ensure flexible installation solutions tailored to client needs;
5. Optional magnetic version with integrated position sensing capability;
6. Pre-machined sensor slot on barrel enables convenient magnetic proximity sensor installation;
7. Comprehensive bore size selection accommodates diverse application requirements.
Category: Multi-position Cylinders | Brand: AIRTAC | Series: MPG
Installation guidance:
Maximum lateral load ≤3N. For vertical mounting,
use counterbalance valve when handling suspended loads.
Maintain 0.5mm clearance between sensor and cylinder body.
2. High-precision piston rod guidance eliminates the need for external lubrication;
3. Advanced rubber encapsulation process on rear cover ensures superior cushioning performance;
4. Multiple mounting configurations and optional accessories ensure flexible installation solutions tailored to client needs;
5. Optional magnetic version with integrated position sensing capability;
6. Pre-machined sensor slot on barrel enables convenient magnetic proximity sensor installation;
7. Comprehensive bore size selection accommodates diverse application requirements.
Category: Multi-position Cylinders | Brand: AIRTAC | Series: MPG
AirTAC MPG Standard Panel Cylinder MPG10X20SN Technical Details
- Model Code: MPG10X20SN
- Type: Double-acting panel mount cylinder
- Bore size: Φ10mm
- Stroke: 20mm (±1mm tolerance)
- Operating pressure: 0.05–0.9 MPa
- Operating temperature: -10℃ to 70℃
- Cushioning: Rubber buffer + adjustable end lock
- Port size: M5×0.8 (Rc1/8 adaptor included)
- Piston rod material: Stainless steel SUS304
- Tube material: Anodized aluminum alloy
- Seal type: HNBR (Hydrogenated Nitrile) seals
- Magnetic sensor compatibility: Built-in magnet for PNP/NPN sensors
- Weight: 0.23kg (excluding accessories)
- Dimensions: 78mm(L) × 34mm(W) × 34mm(H)
- Mounting: Front panel screw mounting (M4×0.7 threads)
- Protection class: IP54 (standard sealing)
- Lubrication: Pre-lubricated (Grease-free operation)
Ultra-compact profile cylinder designed for space-constrained automation systems. Features integrated mounting flanges and precision-ground rod for smooth linear motion. The dual-piston design ensures stable output force (2.5N at 0.5MPa) with minimal air consumption. Compatible with ISO 6432 mounting standards.
Common Applications:
- PCB board clamping mechanisms
- Micro-dosing valve actuators
- 3D printer filament feed systems
- Laboratory sample positioning stages
- Optical lens assembly automation
- Medical device component alignment
Installation guidance:
Maximum lateral load ≤3N. For vertical mounting,
use counterbalance valve when handling suspended loads.
Maintain 0.5mm clearance between sensor and cylinder body.
Maintenance cycle:
Replace seals after 1,000km cumulative travel distance or
5 million cycles (whichever comes first). Use only
ISO VG32 hydraulic oil for relubrication.
| Property | Property Value |
|---|---|
| sku | MPG10X20SN |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M3×0.5 |
| Piston Rod Thread Type | Non-threaded |
| Magnet | S-Magnetic |
| Bore Diameter | <10mm> |
| Stroke | <20mm> |
