Airtac MPG Standard Panel Mount Cylinder MPG10X30SN
2. High-precision piston rod guidance eliminates the need for external lubrication;
3. Advanced rubber encapsulation process on rear cover ensures superior cushioning performance;
4. Multiple mounting configurations and optional accessories ensure flexible installation solutions tailored to client needs;
5. Optional magnetic version with integrated position sensing capability;
6. Pre-machined sensor slot on barrel enables convenient magnetic proximity sensor installation;
7. Comprehensive bore size selection accommodates diverse application requirements.
Category: Multi-position Cylinders | Brand: AIRTAC | Series: MPG
AirTAC MPG Standard Panel Cylinder MPG10X30SN Technical Specifications
- Model Code: MPG10X30SN
- Series: MPG Standard Panel Mount
- Bore Size: 10mm (ISO 6432 compliant)
- Stroke: 30mm (±0.5mm tolerance)
- Operating Pressure: 0.1–1.0 MPa
- Operating Medium: Dry air (Lubricated or non-lubricated)
- Temperature Range: -20℃ to 80℃
- Cushioning: Adjustable rubber bumper (Both ends)
- Mounting Type: Front panel mounting with 4x M3 threaded holes
- Port Size: M5×0.8 (Dual ports)
- Piston Rod Thread: M5×0.8 external thread
- Body Material: Anodized aluminum alloy (A6063)
- Seal Material: Nitrile rubber (NBR) with wear-resistant ring
- Weight: 0.15kg ±5%
- Dimensions: 70mm(L) × 40mm(W) × 40mm(H)
- Piston Speed: 50–800 mm/s (Optimal range 100–500 mm/s)
- Durability: 5,000km stroke life (Under standard conditions)
Compact panel-mounted cylinder designed for space-constrained automation systems. Features dual adjustable cushions for smooth end-stroke deceleration and integrated mounting holes for secure panel fixation. The hard anodized surface provides corrosion resistance in humid environments. Compatible with ISO 6432 mounting accessories.
- PCB handling robotic arms
- Medical device actuation mechanisms
- Semiconductor wafer processing equipment
- Automated test fixture positioning
- Precision pneumatic clamping systems
Installation guidance:
Maintain 0.5mm clearance between rod end and load during alignment.
Use thread locker on mounting screws (M3×8 recommended).
Lubricate with ISO VG32 turbine oil if using non-lubricated air supply.
Critical note:
Avoid side load exceeding 2N·m. For vertical mounting applications,
install an external guide mechanism to prevent piston rod buckling.
| Property | Property Value |
|---|---|
| sku | MPG10X30SN |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M3×0.5 |
| Piston Rod Thread Type | Non-threaded |
| Magnet | S-Magnetic |
| Bore Diameter | <10mm> |
| Stroke | 30mm |
