Airtac MPG Standard Panel Mount Cylinder MPG10X40
2. High-precision piston rod guidance eliminates the need for external lubrication;
3. Advanced rubber encapsulation process on rear cover ensures superior cushioning performance;
4. Multiple mounting configurations and optional accessories ensure flexible installation solutions tailored to client needs;
5. Optional magnetic version with integrated position sensing capability;
6. Pre-machined sensor slot on barrel enables convenient magnetic proximity sensor installation;
7. Comprehensive bore size selection accommodates diverse application requirements.
Category: Multi-position Cylinders | Brand: AIRTAC | Series: MPG
AirTAC MPG Standard Panel Cylinder MPG10X40 Technical Details
- Model: MPG10X40
- Type: Single-acting spring return (panel mount)
- Bore size: 10mm
- Stroke: 40mm (±1mm tolerance)
- Operating pressure: 0.05–0.9 MPa
- Ambient temperature: -20℃ to 80℃
- Port size: M5×0.8 (standard), optional NPT1/8
- Cushioning: Adjustable rubber buffer
- Piston material: Aluminum alloy (hard anodized)
- Rod material: Stainless steel (SUS304)
- Seal type: NBR seals (oil-resistant)
- Weight: 220g ±5g
- Dimensions:
- Body length: 100mm
- Mounting panel cutout: 12.5×12.5mm
- Overall height (extended): 144mm
- Rod end thread: M6×1.0
- ISO standard: 6432 compliant
Ultra-slim profile cylinder specifically engineered for space-constrained panel installations. Features precision-ground rod and dual sealing system for leak-free operation. The front flange design allows tool-free panel mounting with integrated shock absorption. Requires 40μm filtered compressed air with recommended lubrication (ISO VG32).
- PCB handling robots in electronics assembly
- Medical device actuator mechanisms
- Semiconductor wafer positioning systems
- Automated test equipment interfaces
- Precision valve actuation in analytical instruments
Installation guidance:
Ensure panel flatness ≤0.1mm/mm² and use torque-controlled fasteners (1.2-1.5N·m).
Lubricate through port before initial operation. Avoid side loads exceeding 2N.
| Property | Property Value |
|---|---|
| sku | MPG10X40 |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M3×0.5 |
| Piston Rod Thread Type | External Thread |
| Magnet | Non-magnetic |
| Bore Diameter | <10mm> |
| Stroke | <40mm> |
