Airtac MPG Standard Panel Mount Cylinder MPG10X40SN
2. High-precision piston rod guidance eliminates the need for external lubrication;
3. Advanced rubber encapsulation process on rear cover ensures superior cushioning performance;
4. Multiple mounting configurations and optional accessories ensure flexible installation solutions tailored to client needs;
5. Optional magnetic version with integrated position sensing capability;
6. Pre-machined sensor slot on barrel enables convenient magnetic proximity sensor installation;
7. Comprehensive bore size selection accommodates diverse application requirements.
Category: Multi-position Cylinders | Brand: AIRTAC | Series: MPG
AirTAC MPG Series Standard Panel Cylinder MPG10X40SN Technical Details
- Model Code Breakdown: MPG-10-X-40-S-N
- Bore Size: 10mm (ISO 6432 standard)
- Stroke: 40mm (±0.5mm tolerance)
- Structure Type: Double-acting with single piston rod
- Port Thread: M5×0.8 (standard) / G1/8 optional
- Operating Pressure: 0.1-0.9 MPa
- Cushioning: Adjustable rubber buffer (both ends)
- Ambient Temperature: -20℃ to 80℃
- Piston Speed: 50-800 mm/s (optimal range)
- Mounting Style: Front panel mount with T-slot
- Rod End: M4 threaded (female)
- Seal Material: NBR (Nitrile) with wear-resistant guide rings
- Body Material: Anodized aluminum alloy (6063-T5)
- Repeat Positioning Accuracy: ±0.2mm
- Weight: 0.18kg (excluding accessories)
- Dimensions: 120mm(L) × 24mm(W) × 25mm(H)
- ISO Certification: 6432/DIN ISO 15552 compliant
The MPG10X40SN features a space-saving panel-mount design with integrated T-slot for tool-free installation. Its compact profile and magnetic piston enable position feedback when paired with sensors (optional). The cylinder's chrome-plated piston rod and dual cushioning system ensure smooth operation in high-cycle applications. Requires 5μm filtered dry air with ISO 8573-1:2010 Class 3.4.2 air quality.
- PCB handling robots - component insertion mechanisms
- Pharmaceutical blister packaging machines
- Semiconductor wafer sorting equipment
- Automated microscope stage positioning
- Precision dosing valve actuators
- Optical lens assembly systems
Installation protocol:
Lubricate rod with ISO VG32 hydraulic oil before initial use.
Maintain 0.5mm minimum clearance between sensor and magnetic ring.
Avoid side loads exceeding 2N·m. For vertical mounting,
use counterbalance valves (available as MPG-10-CV accessory).
| Property | Property Value |
|---|---|
| sku | MPG10X40SN |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M3×0.5 |
| Piston Rod Thread Type | Non-threaded |
| Magnet | S-Magnetic |
| Bore Diameter | <10mm> |
| Stroke | <40mm> |
