Airtac MPG Standard Panel Mount Cylinder MPG10X5
2. High-precision piston rod guidance eliminates the need for external lubrication;
3. Advanced rubber encapsulation process on rear cover ensures superior cushioning performance;
4. Multiple mounting configurations and optional accessories ensure flexible installation solutions tailored to client needs;
5. Optional magnetic version with integrated position sensing capability;
6. Pre-machined sensor slot on barrel enables convenient magnetic proximity sensor installation;
7. Comprehensive bore size selection accommodates diverse application requirements.
Category: Multi-position Cylinders | Brand: AIRTAC | Series: MPG
AirTAC MPG Standard Panel Cylinder MPG10X5 Technical Specifications
- Model: MPG10X5 (MPG Series)
- Bore size: 10mm
- Stroke: 5mm
- Operating pressure: 0.15–0.8 MPa
- Cushion type: Rubber buffer (both ends)
- Mounting style: Panel-mounted with 4x M3 screws
- Port size: M5x0.8 (Rc1/8 optional)
- Ambient temperature: -20℃ to 80℃
- Piston speed: 50–800 mm/s
- Material:
- Cylinder tube: Aluminum alloy (hard anodized)
- Piston rod: Stainless steel (SUS304)
- Seals: NBR (standard), optional FKM/Viton
- Weight: 0.12kg ±2%
- Dimensions: 54mm(L) × 20mm(W) × 20mm(H)
- Protection rating: IP54 (standard), IP67 optional
- Lubrication: Pre-lubricated (DOP-free grease)
Ultra-compact panel cylinder optimized for space-critical automation systems. Features dual-position mounting holes for flexible panel integration and wear-resistant chromium-plated guide rods. The integrated shock absorption system reduces end-impact noise by 30% compared to basic models. Requires 5μm filtered air with ISO 8573-1:2010 Class 3.4.2 air quality.
- Precision positioning in SMT component insertion machines
- Clamping mechanisms for micro-optics assembly
- Medical device component actuation (IVD analyzers, pipette systems)
- Semiconductor wafer handling robots
- Compact jig fixtures for watch manufacturing
Installation tip:
Maintain ≤0.05mm parallelism between cylinder base and mounting surface.
Use thread-locking adhesive on M3 screws (torque ≤0.4N·m).
For vertical installations, add a drip shield to prevent debris ingress.
| Property | Property Value |
|---|---|
| sku | MPG10X5 |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M3×0.5 |
| Piston Rod Thread Type | External Thread |
| Magnet | Non-magnetic |
| Bore Diameter | <10mm> |
| Stroke | <5mm> |
