Airtac MPGH Hinge Mount Type Cylinder MPGH10X15
AirTAC MPGH Hinge Mount Cylinder MPGH10X15 Technical Details
- Model: MPGH10X15
- Type: Compact hinge-mounted pneumatic cylinder
- Bore size: 10mm
- Stroke: 15mm
- Mounting style: Integrated hinge bracket with 4x M4 threaded holes
- Operating pressure: 0.05–0.9 MPa
- Cushioning: Adjustable rubber bumper (both ends)
- Temperature range: -10℃ to 80℃
- Port size: M5x0.8 (dual ports)
- Rod material: Hard chrome-plated steel
- Tube material: Anodized aluminum alloy
- Seal type: NBR + PU combination
- Weight: 220g ±5%
- Dimensions: 82mm(L) × 40mm(W) × 34mm(H)
- Piston rod diameter: 4mm
- Max theoretical force (@0.6MPa): 47.1N (extend), 41.2N (retract)
- Protection rating: IP54 (standard), IP67 optional
Ultra-compact hinge cylinder designed for space-constrained rotary applications. Features a 360° adjustable mounting bracket with ±2° angular compensation. The dual-port design allows for flexible piping configurations. Includes wear-resistant guide bushings for smooth pivoting motion and anti-rotation pin for torque stability.
- Robotic arm joint articulation
- Semiconductor wafer handling clamps
- Flip-top lid mechanisms in packaging lines
- Precision angular positioning in optical equipment
- Medical device tray rotation systems
Installation tip:
Apply thread locker (Loctite 243 recommended) to hinge pivot bolts.
Lubricate with ISO VG32 hydraulic oil before initial operation.
Max allowable side load: 5N at full extension.
| Property | Property Value |
|---|---|
| sku | MPGH10X15 |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M3×0.5 |
| Piston Rod Thread Type | External Thread |
| Magnet | Non-magnetic |
| Bore Diameter | <10mm> |
| Stroke | <15mm> |
