Airtac MPGH Hinge Mount Type Cylinder MPGH10X20
AirTAC MPGH Hinge Mount Cylinder MPGH10X20 Technical Specifications
- Model: MPGH10X20
- Bore size: 10mm
- Stroke: 20mm (±1mm tolerance)
- Operating pressure: 0.05–0.8 MPa
- Cushion type: Elastic buffer (adjustable optional)
- Mounting style: Hinge bracket (integrated pivot)
- Port thread: PT1/8 (M5×0.8 optional)
- Operating temperature: -20℃ to 80℃
- Piston speed: 50–700 mm/s (lubricated)
- Seal material: NBR (HNBR available for high-temp)
- Rod material: Stainless steel SUS304
- Weight: 0.18kg (excluding accessories)
- Dimensions: 60mm(L) × 18mm(W) × 25mm(H) (minimum retracted length)
- ISO standard: 6432 compliant
- Corrosion resistance: Class CRC2 (salt spray test 48h)
Compact hinge-mounted cylinder featuring low-profile design with integrated pivot mount for angular motion applications. Precision honed aluminum barrel ensures smooth operation with ≤0.15mm concentricity tolerance. Dual rod bearings reduce lateral load stress, optimized for 0.5–1.5N·m torque applications. Requires ISO VG32 hydraulic oil mist lubrication for extended seal life.
- Robotic gripper jaw articulation
- Semiconductor wafer handling arms
- Medical bed adjustment mechanisms
- Automotive assembly clamping fixtures
- Food processing valve actuators
Installation note:
Maintain 0.5–1mm clearance between pivot points during mounting.
Use locknuts with 1.2–1.5N·m tightening torque. Avoid side loads exceeding 3N.
Requires 5–10μm filtration.
Maximum lateral misalignment: ±1.5°.
For vertical mounting, use counterbalance valves.
| Property | Property Value |
|---|---|
| sku | MPGH10X20 |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M3×0.5 |
| Piston Rod Thread Type | External Thread |
| Magnet | Non-magnetic |
| Bore Diameter | <10mm> |
| Stroke | <20mm> |
