Airtac MPGH Hinge Mount Type Cylinder MPGH10X40
$26.95
Regular price
$34.45
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
MPGH10X40
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
The MPGH Hinge-Mounted Cylinder Series by AIRTAC features:
1. Compact design with minimized footprint and lightweight construction for space-efficient integration;
2. High-precision piston rod guidance ensuring stable operation without external lubrication;
3. Advanced rubber-cushioned rear cap technology for superior shock absorption performance;
4. Flexible mounting configurations with customer-selectable accessories for versatile installation;
5. Optional magnet-embedded models enabling position feedback via magnetic sensors;
6. Pre-machined sensor slots on barrel for tool-free magnetic switch installation;
7. Multiple standardized bore sizes available to meet diverse application requirements.
Category: Multi-position Cylinders | Brand: AIRTAC | Series: MPGH
Installation note:
Align pivot axis within 0.2mm parallelism tolerance. Apply thread lock (Loctite 243 recommended)
to hinge screws. Allow 2-3mm clearance for swing arc during full stroke operation.
Maintenance alert:
Inspect pivot bushings every 500,000 cycles in normal conditions (100,000 cycles in high-side-load applications).
Use only pneumatic-grade lubricants compatible with NBR seals.
AirTAC MPGH Hinge Mount Cylinder MPGH10X40 Specifications
- Model: MPGH10X40
- Type: Hinge-mounted compact cylinder (double-acting)
- Bore size: 10mm
- Stroke: 40mm (±1mm tolerance)
- Operating pressure: 0.05–0.7 MPa
- Cushioning: Rubber buffer (adjustable both ends)
- Mounting: Standard hinge bracket (M5x0.8 mounting screws included)
- Port size: M5x0.8 (Rc1/8 adaptor optional)
- Piston rod material: Hard chrome-plated steel
- Tube material: Anodized aluminum alloy
- Seal material: NBR (Nitrile rubber)
- Temperature range: -20℃ to 80℃
- Weight: 0.25kg (excluding accessories)
- Dimensions: 125mm(L) × 28mm(W) × 42mm(H) (at mid-stroke position)
- Max theoretical force: 34.3N @0.5MPa
- Air consumption: 3.14cm³/stroke @0.5MPa
- Lubrication: Pre-lubricated (Use ISO VG32 turbine oil if re-lubrication needed)
Ultra-slim hinge cylinder with integrated pivot mechanism, optimized for confined spaces requiring angular motion. Features wear-resistant guide structure and dual anti-rotation pins for precise linear-to-rotary conversion. Includes built-in mounting boss for secondary fixture security.
Typical Applications:
- Rotating clamps in semiconductor handling robots
- Compact door actuators in cleanroom equipment
- Precision paper feeding mechanisms in printers
- Angular positioning in automated test fixtures
- Packaging machine flap control systems
Installation note:
Align pivot axis within 0.2mm parallelism tolerance. Apply thread lock (Loctite 243 recommended)
to hinge screws. Allow 2-3mm clearance for swing arc during full stroke operation.
Maintenance alert:
Inspect pivot bushings every 500,000 cycles in normal conditions (100,000 cycles in high-side-load applications).
Use only pneumatic-grade lubricants compatible with NBR seals.
| Property | Property Value |
|---|---|
| sku | MPGH10X40 |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M3×0.5 |
| Piston Rod Thread Type | External Thread |
| Magnet | Non-magnetic |
| Bore Diameter | <10mm> |
| Stroke | <40mm> |
